- Name
- Z-Wave Key-Free Touch Deadbolt(KA210-P )
- Brand
- Kaadas
- Texts
- ID Description Value 8
- Features
- Feature Values Battery Quantity
- Is flirs
- Yes
- Documents
- Category File Manual_English
- Role type
- ROLE_TYPE_END_NODE_SLEEPING_LISTENING
- User icon
- 0x0300
- Categories
- Locks
- Product id
- 0x0326
- S2 classes
- S2_ACCESS_CONTROL
- Device type
- Lock DT
- Oem version
- HW: 38 FW: 02.00:50.10:50.10
- Library type
- END_NODE_ENHANCED_232
- Product line
- Z-Wave Plus v2 Devices
- Supports nwi
- Yes
- Installer icon
- 0x0300
- Z wave version
- 7.18.8
- Frequency plans
- US: 916.00MHz, 908.40MHz, ANZ: 919.80MHz, 921.40MHz, CN: 868.40MHz, EU: 869.85MHz, 868.40MHz, HK: 919.80MHz, 919.80MHz, IL: 916.00MHz, IN: 865.20MHz, JP: 922.50MHz, 923.90MHz, 926.30MHz, KR: 920.90MHz, 921.70MHz, 923.10MHz, RU: 869.00MHz, US_LR: 912.00MHz, 920.00MHz
- Manufacturer id
- 0x021D
- Product type id
- 0x0103
- Long description
- KA210-P is a smart key-free touchsecreen lock with Z-Wave® and Bluetooth communication,and it is available in three colcor finishes:Satin Nickel,Oil Rubbed Bronze and Matte Black. Integrated with a variety of functions such as 250 user PIN Code,One-Time PIN Code,Auto relock,One-Touch Locking,Silent Mode,Away Mode,Wrong Code Entry Limit etc.For 250 groups User PIN code,All PIN codes can be set as schedule PIN by Z-Wave ,schedule PIN Code including One-time PIN code,Duration PIN code,Weekly PIN code,Monthly PIN code(same day every month),Yearly PIN code(same day every year),you can set it up according to your own needs.
- Hardware platform
- ZGM130S037HGN2 / ZGM130S037HGN1
- Short description
- KA210-P is a smart key-free touchsecreen lock with Z-Wave® and Bluetooth communication,and it is available in three colcor finishes:Satin Nickel,Oil Rubbed Bronze and Matte Black.
- Product identifier
- KA210-P
- Countries / regions
- Argentina, Bahamas, Barbados, Bermuda, Bolivia, British Virgin Islands, Canada, Cayman Islands, Colombia, Guatemala, Haiti, Honduras, Jamaica, Mexico, Panama, Saint Kitts and Nevis, Suriname, Trinidad and Tobago, Turks and Caicos Islands, United States of America, Australia, Brazil, Chile, El Salvador, Indonesia, Malaysia, New Zealand, Paraguay, Peru, Uruguay, Venezuela, Vietnam, China, Morocco, Armenia, Bahrain, European Union, Cyprus, Moldova, Egypt, French Guiana, Georgia, Iraq, Jordan, Kazakhstan, Kuwait, Lebanon, Libya, Maldives, Mauritius, Nigeria, Oman, Philippines, Qatar, Saudi Arabia, South Africa, Turkmenistan, United Arab Emirates, ZU, Yemen, Hong Kong, Israel, India, Costa Rica, Japan, Macao, Singapore, Republic of Korea, Taiwan, Thailand, Russian Federation
- Supports smart start
- Yes
- Certification number
- ZC14-24100476
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value 1
- Supports explorer frames
- Yes
- Radio range z wave lr (m)
- 400
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_BASIC_V2
- Supported notification types
- Notification Type Event / State Access Control
- Value 4 battery type value aa alkaline battery door lock type value deadbolt firmware updatable value updatable by consumer by rf association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile 1
