- Name
- Gateway Controller
- Brand
- MITSUMI
- Texts
- ID Description Value 8
- Features
- Feature Values Color
- Documents
- Category File Manual_English
- Role type
- ROLE_TYPE_CONTROLLER_CENTRAL_STATIC
- User icon
- 0x0500
- Categories
- Gateway Controller
- Identifier
- ITB-5105
- Product id
- 0x0002
- S2 classes
- S2_ACCESS_CONTROL, S2_AUTHENTICATED, S2_UNAUTHENTICATED
- Description
- Gateway Controller to IoT with functions of wired LAN and Z-Wave™ communication.
- Device type
- Gateway DT
- Oem version
- HW: 01 FW: 07.14:07.14
- Library type
- CONTROLLER_BRIDGE
- Product line
- "ITB-xxxx" Series
- Supports nwi
- Yes
- Installer icon
- 0x0500
- Z wave version
- 7.14.3
- Frequency plans
- JP: 922.50MHz, 923.90MHz, 926.30MHz
- Manufacturer id
- 0x0112
- Product type id
- 0x0010
- Hardware platform
- ZGM130S037HGN2 / ZGM130S037HGN1
- Short description
- Gateway Controller
- Countries / regions
- Japan
- Supports smart start
- Yes
- Certification number
- ZC14-21080003
- Radio range z wave (m)
- 40
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_CRC_16_ENCAP
- Controlled command classes
- Identifier Name Key Version COMMAND_CLASS_CRC_16_ENCAP
- Value black controller supports multiple networks value 0 gateway has preferred partners value 0 ip (ingress protection) rated value 0 association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile 1
