coqon qbox

Name

coqon qbox

Brand

Neusta Next GmbH

Texts

ID Description Value 23

Features

Feature Values Sensors

Documents

Category Description File Manual_Primary_Lang

Role type

ROLE_TYPE_CONTROLLER_CENTRAL_STATIC

User icon

05 00

Categories

All Controllers, Gateway Controller

Product id

0x0001

Device type

Gateway

Oem version

HW: 0 FW: 4.20:02.00:01.00:01.00

Library type

CONTROLLER_BRIDGE

Supports nwi

Yes

Installer icon

05 00

Z wave version

6.51.06

Frequency plans

EU: 869.85MHz, 868.40MHz

Manufacturer id

0x0248

Product type id

0x0001

Long description

The qbox is the powerful heart of COQON. All Home devices are connected to the qbox via wireless technology. The qbox makes it possible to control all componentens in the coqon ecosystem via apps or webfrontend, either locally or from remote. With modern encryption technology coqon is perfectly secure. Teh qbox is designed to be plug & play and can be placed on a tbale or wall-mounted.

Hardware platform

ZM5304

Short description

The coqon qbox is the central controller for the coqon smart living system. It acts as a central Z-Wave controller, that enables the user to control a Z-Wave network and provides additional automation functionality

Product identifier

CQNGATEV1

Countries / regions

European Union

Certification number

ZC10-16095210

Radio range z wave (m)

40

Supports explorer frames

Yes

Controlled command classes

Identifier Name Key Version COMMAND_CLASS_SWITCH_BINARY_V2

Supported / controlled meter types

Meter Type Rate Type Description Electric meter

Value motion/no motion (binary) air temperature open/closed (binary) smoke density heat water flow carbon dioxide carbon monoxide supported meter type value electric energy switch type value toggle thermostat hvac systems supported value heat only window covering control features value position aware association groups

Group Number Maximum Nodes Supported End Point ID Description 1
