J-Series by Schlage Z-Wave Keypad Deadbolt

Loading…

J-Series by Schlage Z-Wave Keypad Deadbolt — Schlage — Off Screen Space

More specs

Name: J-Series by Schlage Z-Wave Keypad Deadbolt
Brand: Schlage
Features: Feature Values Door Lock Type
Is flirs: Yes
Documents: Category Description File Manual_English
Role type: ROLE_TYPE_SLAVE_SLEEPING_LISTENING
User icon: 0x0300
Categories: Locks
Product id: 0x2109
S2 classes: S2_ACCESS_CONTROL
Device type: Lock
Oem version: HW: 3 FW: 1.09:01.13
Library type: SLAVE_ENHANCED_232
Product line: J-Series
Supports nwi: Yes
Installer icon: 0x0300
Z wave version: 7.11.1
Frequency plans: US: 916.00MHz, 908.40MHz
Manufacturer id: 0x003B
Product type id: 0x0004
Long description: The J-Series by Schlage Z-Wave Deadbolt combines advanced features and compatibility with your home automation or security system, allowing you to control your lock from anywhere and freeing you from the hassles of lost keys, getting locked out, or hiding a spare for friends and family. The lock comes preprogrammed with two access codes and can hold up to 30 unique codes for family members and trusted friends. The J-Series by Schlage Z-Wave Deadbolt is battery-powered with a low battery warning that gives you weeks of advanced notice before it runs out. With guaranteed fit on standard doors, it’s easy for homeowners to install in minutes with just a screwdriver. The touchscreen continues to work in the event of a power outage, so you don’t have to worry about getting locked out – plus, a back-up key is included with the lock for peace of mind. The J-Series by Schlage Z-Wave Deadbolt incorporates Z-Wave Plus S2 technology, an enhanced security protocol that features an additional layer of AES encryption of wireless signals. The Z-Wave technology allows you to integrate your exterior door locks with other Z-Wave smart home devices, such as cameras, motion detectors, lights and thermostats, bringing the safety, simplicity and style of Schlage to your smart home.
Hardware platform: ZGM130
Short description: The J-Series by Schlage Z-Wave Deadbolt combines advanced features and compatibility with home automation or security systems, so you can control your lock from anywhere using your smartphone.
Product identifier: JBE109
Countries / regions: United States of America
Supports smart start: Yes
Certification number: ZC12-21040221
Radio range z wave (m): 40
Configuration parameters: Parameter Number Name Description Format Read-only Size Min Value Max Value Default Value Parameter Values 6
Supports explorer frames: Yes
Supported command classes: Identifier Name Key Version COMMAND_CLASS_CONFIGURATION_V4
Controlled command classes: Identifier Name Key Version COMMAND_CLASS_TIME
Supported notification types: Notification Type Event / State Access Control
Value deadbolt battery type battery quantity association groups: Group Number Maximum Nodes Supported End Point ID Group Name Description 1
From to description 1 1 user slots 8 – 1 (msb – lsb) 8,7,6,5,4,3,2,1 2 2 user slots 16 – 9 (msb – lsb) 16,15,14,13,12,11,10,9 3 3 user slots 24 – 17 (msb – lsb) 24,23,22,21,20,19,18,17 4 4 user slots 30 – 25 (msb – lsb) x,x,30,29,28,27,26,25 3 beeper config enable snd ff else 00 2 1 0 255 255 from to description 0 0 disable beeper 255 255 enable beeper 4 vacation mode config enable snd ff else 00 2 1 0 255 0 from to description 0 0 disable vacation mode 255 255 enable vacation mode 5 lock and leave config enable snd ff else 00 2 1 0 255 255 from to description 255 255 enable lock & leave 0 0 disable lock & leave texts: ID Description Value 1
