ORA ZRX 10/17 — Cherubini — Off Screen Space

More specs

Name: ORA ZRX 10/17
Brand: Cherubini
Texts: ID Description Value 8
Features: Feature Values Window Covering Control Features
Documents: Category File Adv_Manual
Role type: ROLE_TYPE_SLAVE_ALWAYS_ON
User icon: 0x1a00
Categories: Window Covering, Motor Control
Product id: 0x0001
S2 classes: S2_AUTHENTICATED, S2_UNAUTHENTICATED
Device type: Window Covering DT
Oem version: HW: 01 FW: 02.01
Library type: END_NODE_ENHANCED_232
Product line: Z-Wave 700
Supports nwi: Yes
Installer icon: 0x1a00
Z wave version: 7.16.3
Frequency plans: EU: 869.85MHz, 868.40MHz
Manufacturer id: 0x0455
Product type id: 0x0004
Long description: ORA ZRX is a motor for awnings, pergolas and screens, with programmable limit switches, dual-radio control and wired control option. Electronic limit switch with integrated dual-radio Cherubini CRC RZ and Z-Wave™. The motor can be controlled by voice assistants (Google Home and Amazon Alexa) and CRC RX radio remote controls, switches, and online applications associated with the gateway. The motor keeps its status aligned for any type of command received: via cable through push button or switch, via CRC RX radio through remote control, via Z-Wave network, via voice assistant, tablet or smartphone. The limit switches can be adjusted manually, or acquired automatically by the motor, if the roller shutter is equipped with mechanical stop devices, on the up and/or down motion. Climate Alerts Intelligence The device is able to send a notification based on the information provided by the sensors linked to the motor (Wind, Rain, Solar) so it can recognize Wind, Rain, and Sun alerts and decide to open/close the awning based on the configuration. Recognizes obstacles Notification is send when the motor reaches an obstacle during its operation. Z-Wave serie 700, SmartStart and S2 security. Power supply: 230 VAC±10% 50/60 Hz Work Temperature: -10° to 40°C Maximum distance: Up to 100 m outdoors – up to 40 m indoor Power consumption in stand by: < 1W
Hardware platform: ZGM130S037HGN2 / ZGM130S037HGN1
Short description: ORA ZRX is a dual radio motor for awnings and pergolas, with programmable limit switches, and wired control option. The dual-radio control allows, on the one hand, the adjustment of the limit switches and the main functions to be carried out simply and interactively and, on the other hand, to be integrated into a Z-Wave™ network. The wired control option provides for both programming and motor control, from a simple switch, as an addition or as an alternative to the radio remote control.
Product identifier: CZT45101700
Countries / regions: European Union
Supports smart start: Yes
Certification number: ZC14-23030204
Radio range z wave (m): 40
Configuration parameters: Parameter Number Name Description Format Size Min Value Max Value Default Value 31
Supports explorer frames: Yes
Supported command classes: Identifier Name Key Version COMMAND_CLASS_BASIC_V2
Supported notification types: Notification Type Event / State System
Value position aware manual calibration supports curtains supports horizontal blinds/louvers supports open/close motion association groups: Group Number Maximum Nodes Supported End Point ID Group Name Profile 1
