- Name
- 2-Channel Dimmer
- Brand
- CONFIO
- Features
- Feature Values Loads Controlled
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x0600
- Categories
- All Lighting Devices, Dimming Lighting Devices, On/Off Switches/Devices
- Product id
- 0xC002
- S2 classes
- S2_UNAUTHENTICATED
- Device type
- Light Dimmer Switch
- Oem version
- HW: 1 FW: 1.00
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Installer icon
- 0x0600
- Z wave version
- 6.81.03
- Frequency plans
- IN: 865.20MHz
- Manufacturer id
- 0x0419
- Product type id
- 0x4000
- Long description
- CT2D is a 2-channel multilevel power socket capable of dimming Incandescent lamps and dimmable LED lights. Both channels/loads operate independently, Two corresponding local switches and potentiometers are available to directly control these channels irrespective of inclusion state. Local switches can be configured to different modes. CT2D Channel #1: TRIAC/FET based edge control dimming. This channel can be operated in two modes LEC/TEC respectively. CT2D Channel #2: PWM dimmer. This channel is capable of dimming LED lamps which have PWM dimming capabilities. This needs a PWM enabled LED driver. CT2D can be used out of the box and needs no configuration. However, it supports different configuration parameters that extend its functionality
- Hardware platform
- ZM5101
- Short description
- CT2D is a two-channel multilevel power socket with one channel Phase Cut and another PWM, capable of dimming Incandescent lamps and dimmable LED lights.
- Product identifier
- CT2D
- Countries / regions
- India
- Supports smart start
- Yes
- Certification number
- ZC10-19096735
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 3
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_SWITCH_MULTILEVEL
- Value 2 switch load capacity watts value 300 neutral wire required firmware updatable value updatable by manufacturer electric load type value incandescent led dimmable led dimmable mlv (magnetic) dimmable elv (magnetic) association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
- From to description 0 1 0: instant, 1: smooth 4 dimming preference for pwm led load this parameter switch between the dimming preference smooth dimming or instant dimming for the load connected on dim+/ channel. 0 1 0 0 1 from to description 0 1 0: instant, 1: smooth 5 dimming speed for tec/lec load this parameter sets the dimming speed of load connected on tec/lec channel 0 1 0 0 3 from to description 1 5 1: very fast, 2: fast, 3: medium, 4: slow, 5: very slow 6 dimming speed for pwm led load this parameter sets the dimming speed of load connected on pwm led channel. 0 1 0 0 3 from to description 1 5 1: very fast, 2: fast, 3: medium, 4: slow, 5: very slow 7 potentiometer status (rsw1 & rsw2) this parameter enable/disable potentiometer service for both tec/lec and pwm led loads. 0 1 0 0 3 from to description 0 3 0: rsw1 & rsw2 disable, 1: rsw1 enable, 2: rsw2 enable, 3: rsw1 & rsw2 enable 8 sw1 functionality this parameter switch between the switch functionality for sw1 i.e. position switch or toggle switch or bell switch dimming 0 1 0 0 2 from to description 0 2 0: position switch on to on and off to off, 1: toggle switch, 2: bell switch 9 sw2 functionality this parameter switch between the switch functionality for sw2 i.e. position switch or toggle switch or bell switch dimming. 0 1 0 0 2 from to description 0 2 0: position switch on to on and off to off, 1: toggle switch, 2: bell switch 10 on board led enable/disable this parameter enables or disables onboard leds. 0 1 0 0 1 from to description 0 1 0: disable, 1: enable 1 power on status of tec/lec load this parameter decides the power on state (when the module is powered on) of load connected on tec or lec channel. this parameter provides two options either power on to memory (previous state as it was before power off) or present switch position. 0 1 0 0 1 from to description 0 1 0: switch sw1, 1: memory) 2 power on status of pwm led load this parameter decides the power on state (when the module is powered on) of load connected on dim+/ channel. this parameter provides two options either power on to memory (previous state as it was before power off) or present switch position. 0 1 0 0 1 from to description 0 1 0: switch sw2, 1: memory texts
