- Name
- S2 Remote Control Switch
- Brand
- EVA LOGIK
- Features
- Feature Values Color
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_SLEEPING_REPORTING
- User icon
- 0x0A00
- Categories
- All Controllers, Handheld Controller
- Product id
- 0xF001
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Central Scene Device
- Oem version
- HW: 1 FW: 1.00
- Library type
- SLAVE_ENHANCED_232
- Product line
- Line A
- Supports nwi
- Yes
- Installer icon
- 0x0A00
- Z wave version
- 7.13.6
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x0312
- Product type id
- 0x7000
- Long description
- Custom lighting control is at your fingertips with the Z-Wave 2-Button Portable Hub Remote. This versatile remote communicates with your hub to activate up to 6 unique, lighting scenes. Once the remote is connected to your existing network, you can begin programming the lights to personalize your indoor space. The wireless lighting control has an overall signal range of up to 150 feet and is compatible with any device that works with your hub.
- Hardware platform
- ZGM130
- Short description
- Custom lighting control is at your fingertips with the Jasco Z-Wave 2-Button Portable Hub Remote. This versatile remote communicates with your hub to activate up to 6 unique, lighting scenes. Once the remote is connected to your existing network, you can begin programming the lights to personalize your indoor space.
- Product identifier
- ZW922
- Countries / regions
- United States of America
- Supports smart start
- Yes
- Certification number
- ZC12-21020180
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 3
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_CONFIGURATION_V4
- Value white z wave scene type value central scene firmware updatable value updatable by consumer by rf battery type value cr2032 association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Description 1
- From to description 0 0 white 1 1 blue 2 2 green 3 3 red 4 4 magenta 5 5 yellow 6 6 cyan 2 led indicator color for upper paddle remote cont paramter no: 2(0x02) size:1 byte (default=1) value: 00 white value: 01 blue value: 02 green value: 03 red value: 04 magenta value: 05 yellow value: 06 cyan 2 1 0 6 1 from to description 0 0 white 1 1 blue 2 2 green 3 3 red 4 4 magenta 5 5 yellow 6 6 cyan 1 led indicator mode paramter no: 1(0x01) size:1 byte (default=1) value: 00 led always off value: 01 led normal mode value: 02 led always on in color specified in parameter 2 value: 03 led always on in color specified in parameter 3 2 1 0 3 1 from to description 0 0 led always off 1 1 led normal mode 2 2 led always on in color specified in parameter 2 3 3 led always on in color specified in parameter 3 texts
- ID Description Value 2
