- Name
- Wave i4 DC
- Brand
- Shelly Qubino
- Texts
- ID Description Value 8
- Features
- Feature Values Color
- Documents
- Category File Manual_English
- Role type
- ROLE_TYPE_END_NODE_ALWAYS_ON
- User icon
- 0x1D04
- Categories
- All Controllers
- Product id
- 0x0082
- S2 classes
- S2_AUTHENTICATED, S2_UNAUTHENTICATED
- Device type
- Central Scene DT
- Oem version
- HW: 01 FW: 11.01:02.02
- Library type
- END_NODE_ENHANCED_232
- Product line
- Wave
- Supports nwi
- Yes
- Installer icon
- 0x1D04
- Z wave version
- 7.20.2
- Frequency plans
- EU: 869.85MHz, 868.40MHz
- Manufacturer id
- 0x0460
- Product type id
- 0x0009
- Long description
- Z-Wave® 4-digital inputs controller for enhanced actions control. Manually activate or deactivate any created scene, run synchronized actions, or execute complex trigger scenarios. Wave i4 DC is an input reader device (it does not contain relays). Manually control other Z-Wave devices (e.g. with a multi-button switch) Multi-click – activation of up to 12 actions Extremely low power consumption: < 0.3 W Z-Wave frequency band: 868.4 MHz (CEPT countries) Latest technology: Z-Wave 800 Series Automatic set-up with SmartStart Security 2 Authenticated for the highest level of security Over-the-air firmware updates Works with Z-Wave-certified gateways and over 4,000 Z-Wave devices
- Hardware platform
- ZGM230SA
- Short description
- Wave i4 DC is a 4-digital inputs module (5-24 V DC) that controls other devices within the Z-Wave network. It enables manual activation or deactivation of scenes through a switch/push-button.
- Product identifier
- QNSN-0D24XEU
- Countries / regions
- Armenia, Bahrain, European Union, Cyprus, Moldova, Egypt, French Guiana, Georgia, Iraq, Jordan, Kazakhstan, Kuwait, Lebanon, Libya, Maldives, Mauritius, Nigeria, Oman, Philippines, Qatar, Saudi Arabia, South Africa, Turkmenistan, United Arab Emirates, ZU, Yemen
- Supports smart start
- Yes
- Certification number
- ZC14-24020413
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Flag Advanced Read-only 1
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_CENTRAL_SCENE_V3
- Supported notification types
- Notification Type Event / State Heat Alarm
- Value yellow firmware updatable value updatable by consumer by rf neutral wire required value 1 switch type value push button association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile 1
