- Name
- IR Transceiver
- Brand
- Hank
- Features
- Feature Values Color
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x0900
- Categories
- Infrared Devices
- Product id
- 0x0007
- Device type
- AV Control Point
- Oem version
- HW: 1 FW: 1.00:01.00
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Installer icon
- 0x0900
- Z wave version
- 6.51.09
- Frequency plans
- EU: 869.85MHz, 868.40MHz
- Manufacturer id
- 0x0208
- Product type id
- 0x0100
- Long description
- ACC01 is an IR Transceiver based on ZWAVE technology. It is used for sending IR codes to infrared communication controlling devices such as TV , air condition and TV box .
- Hardware platform
- ZM5202
- Short description
- ACC01 is an IR Transceiver based on ZWAVE technology.
- Product identifier
- HKZW-ACC01
- Countries / regions
- European Union
- Certification number
- ZC10-17035507
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 93
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_POWERLEVEL
- Value black communications protocol value manufacturer proprietary protocol firmware updatable value updatable by consumer by rf association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
- From to description 1431655765 1431655765 device will clear all stored ir code. 254 enable/disable the configuration command lock/unlock all configuration parameters. 0 1 0 0 0 from to description 0 0 unlock 1 1 lock 255 reset device reset to factory default settings and removed from the z wave network. 0 4 0 0 0 from to description 1431655765 1431655765 reset to factory default settings and removed from the z wave network. texts
- ID Description Value 1
