- Name
- In-Wall Smart Dimmer
- Brand
- iDevices
- Features
- Feature Values Electric Load Type
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x0600
- Categories
- All Lighting Devices, Dimming Lighting Devices, Lighting Accessories
- Product id
- 0x3236
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Light Dimmer Switch
- Oem version
- HW: 255 FW: 5.55
- Library type
- SLAVE_ENHANCED_232
- Product line
- Wireless Lighting Controls
- Supports nwi
- Yes
- Installer icon
- 0x0604
- Z wave version
- 6.81.03
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x0458
- Product type id
- 0x4944
- Long description
- Z-Wave Plus™ In-Wall Smart Dimmer replaces existing light switch and allows remote control from any Z-Wave™ certified hub.
- Hardware platform
- ZM5202
- Short description
- Z-Wave Plus™ In-Wall Smart Dimmer replaces existing light switch and allows remote control from any Z-Wave™ certified hub.
- Product identifier
- 61303/ZW3010
- Countries / regions
- United States of America
- Supports smart start
- Yes
- Certification number
- ZC10-21107056
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Read-only Size Min Value Max Value Default Value Parameter Values 3
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_CONFIGURATION_V4
- Controlled command classes
- Identifier Name Key Version COMMAND_CLASS_BASIC_V2
- Value incandescent dimmable led firmware updatable value updatable by consumer by rf neutral wire required switch load capacity watts value 300 switch type value decorator paddle push with indicator z wave scene type value scene & central scene association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Description 3
- From to description 0 0 device is on, led is off; device is off, led is on 1 1 device is on, led is on; device is off, led is off 2 2 led always off 3 3 led always on 31 maximum brightness threshold maximum brightness threshold 1 yes 1 1 99 0 from to description 1 99 set the maximum brightness threshold when manually or remotely controlled 6 dim up/down rate dim up/down rate 1 yes 1 0 1 0 from to description 0 0 dim up/down the light to the specified level quickly by command except value 0 and ff 1 1 dim up/down the light to the specified level slowly by command except value 0 and ff texts
- ID Description Value 8
