- Name
- Nexia One Touch
- Brand
- Ingersoll Rand - Nexia Home Intelligence
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_PORTABLE
- Categories
- All Lighting Devices, Lighting Accessories
- Product id
- 0x4735
- Device type
- Wall Controller
- Oem version
- 01
- Library type
- SLAVE_ROUTING
- Supports nwi
- Yes
- Z wave version
- 6.51.06
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x0178
- Product type id
- 0x5343
- Long description
- The Nexia One Touch is a wall controller device that can act as a central scene controller or a traditional stand-alone scene controller. The Nexia One Touch contains up to 15 different scenes organized in 3 pages of screen where each page contains 5 scenes. The Nexia One Touch conveniently runs up to 15 modes and automations with the tap of a button.
- Hardware platform
- ZM5202
- Short description
- The Nexia One Touch is a wall controller device that can act as a central scene controller or a traditional stand-alone scene controller.
- Association groups
- Group Number Maximum Nodes Supported End Point ID Description 7
- Product identifier
- NX1000
- Countries / regions
- United States of America
- Certification number
- ZC10-15070012
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 4
- Supports explorer frames
- Yes
- Controlled command classes
- Identifier Name Key Version COMMAND_CLASS_BASIC
- From to description 0 4 0x00 = central scene 0x01 = scene control momentary 0x02 = basicset toggle 0x03 = scene control/basicset toggle 0x04 = thermostat 1 reserved reserved 0 1 0 0 0 from to description 0 0 reserved 2 button 1 type configuration for the type of button and which commands it will send when pressed. 0 1 0 0 0 from to description 0 4 0x00 = central scene 0x01 = scene control momentary 0x02 = basicset toggle 0x03 = scene control/basicset toggle 0x04 = thermostat 5 button 4 type configuration for the type of button and which commands it will send when pressed. 0 1 0 0 0 from to description 0 4 0x00 = central scene 0x01 = scene control momentary 0x02 = basicset toggle 0x03 = scene control/basicset toggle 0x04 = thermostat 3 button 2 type configuration for the type of button and which commands it will send when pressed. 0 1 0 0 0 from to description 0 4 0x00 = central scene 0x01 = scene control momentary 0x02 = basicset toggle 0x03 = scene control/basicset toggle 0x04 = thermostat 6 button 5 type configuration for the type of button and which commands it will send when pressed. 0 1 0 0 0 from to description 0 4 0x00 = central scene 0x01 = scene control momentary 0x02 = basicset toggle 0x03 = scene control/basicset toggle 0x04 = thermostat 7 button 6 type configuration for the type of button and which commands it will send when pressed. 0 1 0 0 0 from to description 0 4 0x00 = central scene 0x01 = scene control momentary 0x02 = basicset toggle 0x03 = scene control/basicset toggle 0x04 = thermostat 9 button 8 type configuration for the type of button and which commands it will send when pressed. 0 1 0 0 0 from to description 0 4 0x00 = central scene 0x01 = scene control momentary 0x02 = basicset toggle 0x03 = scene control/basicset toggle 0x04 = thermostat 10 button 9 type configuration for the type of button and which commands it will send when pressed. 0 1 0 0 0 from to description 0 4 0x00 = central scene 0x01 = scene control momentary 0x02 = basicset toggle 0x03 = scene control/basicset toggle 0x04 = thermostat 11 button 10 type configuration for the type of button and which commands it will send when pressed. 0 1 0 0 0 from to description 0 4 0x00 = central scene 0x01 = scene control momentary 0x02 = basicset toggle 0x03 = scene control/basicset toggle 0x04 = thermostat 23 button led level button led brightness level 0 1 0 0 5 from to description 1 10 1=10% 10 = 100% 24 backlight level backlight brightness level 0 1 0 0 5 from to description 1 10 1=10% 10 = 100% 17 reserved 0 1 0 0 0 from to 0 0 texts
