ZOE SHUTTER H

Master · Shade

ZOE SHUTTER H

View all Master products

Connectivity: Z-WaveCategory: Shade

Z-WaveCertified

ZoeShutter is a line-powered Z-Wave interface for 1 actuation (roller shutter) and 2 pushbuttons (opening/closing). Compatible with any Vesta board HM02000+HA40000/HA40100/HA40200. Supports secure mode (Z-Wave™ network security mode) with AES-128 encryption. Advanced microprocessor control. Works with pushbuttons. To be installed in wall switch boxes of dimensions allowing for installation, conforming to provisions of applicable regulations. ZoeShutter can work as stand-alone device, and can be connected to a Z-Wave™ network.

Want to buy adds it to your wish list and follows Master for updates. I own it adds it to your collection.

Compare

vs Competitor ▾

Connectivity

Z-Wave

Firmware

Current version HW: 2 FW: 6.04:06.05

Specifications

Overview

Company: Master
Category: Shade
Device type: Window Covering - Pos/End Aware

Connectivity

Standard / protocol: Z-Wave
Connectivity: Z-Wave
Transport: Z-Wave
Spec version: 6.51.09
Z-Wave frequency: ANZ: 919.80MHz, 921.40MHz

Certification & compliance

Certificate ID

Community tags

Be the first to tag this page — tags appear right away. Try a theme, capability, or subject (e.g. WWII, heist, slow burn, time travel, A24).

More specs

Name: ZOE SHUTTER H
Brand: Master
Features: Feature Values Color
Documents: Category Description File Manual_Primary_Lang
Role type: ROLE_TYPE_SLAVE_ALWAYS_ON
User icon: 0x1A00
Categories: Energy Meters, Window Covering
Product id: 0x0071
Device type: Window Covering - Pos/End Aware
Oem version: HW: 2 FW: 6.04:06.05
Library type: SLAVE_ENHANCED_232
Product line: UNA Automation
Supports nwi: Yes
Installer icon: 0x1A00
Z wave version: 6.51.09
Frequency plans: ANZ: 919.80MHz, 921.40MHz
Manufacturer id: 0x0440
Product type id: 0x0003
Long description: ZoeShutter is a line-powered Z-Wave interface for 1 actuation (roller shutter) and 2 pushbuttons (opening/closing). Compatible with any Vesta board HM02000+HA40000/HA40100/HA40200. Supports secure mode (Z-Wave™ network security mode) with AES-128 encryption. Advanced microprocessor control. Works with pushbuttons. To be installed in wall switch boxes of dimensions allowing for installation, conforming to provisions of applicable regulations. ZoeShutter can work as stand-alone device, and can be connected to a Z-Wave™ network.
Hardware platform: ZM5202
Short description: Shutter up/down, Watt measurement, kWh Measurement, Automatically turn ON/OFF, Associations, Z-Wave™ Repeater, Auto-inclusion, temperature measurement.
Product identifier: HZ07100
Countries / regions: Australia
Certification number: ZC10-22017068
Radio range z wave (m): 40
Configuration parameters: Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 10
Supports explorer frames: Yes
Supported command classes: Identifier Name Key Version COMMAND_CLASS_POWERLEVEL
Controlled command classes: Identifier Name Key Version COMMAND_CLASS_BASIC
Supported multilevel sensors: Multilevel Sensor Type Air temperature
Supported notification types: Notification Type Event / State Power Management
Supported / controlled meter types: Meter Type Rate Type Description Electric meter
Value antique brass electric load type neutral wire required switch load capacity current switch load capacity watts window covering control features association groups: Group Number Maximum Nodes Supported End Point ID Group Name Description 1

From to description 0 0 all on is not active all off is not active 1 1 all on is not active all off active 2 2 all on active all off is not active 255 255 all on active, all off active. 42 power reporting in watts by time interval for q1 or q2 set value means time interval (0 – 32767) in seconds, when power report is send. available configuration parameters (data type is 2 byte dec): • default value 0 = reporting disabled • 0 reporting disabled • 1 32767 = 1 second 32767 seconds. reporting enabled, power report is send with time interval set by entered value. 1 2 0 32767 0 from to description 0 0 power consumption reporting disabled 1 32767 1 32767 seconds. power consumption reporting enabled. report is sent according to time interval (value) set here 71 operating modes this parameter defines selection between two available operating modes. available configuration parameters (data type is 1 byte dec): • default value 0 • 0 shutter mode • 1 venetian mode (up/down and slate rotation) note1: after parameter change, first exclude module (without setting parameters to default value) then wait at least 30s and then re include the module! 1 1 0 1 0 from to description 0 0 shutter mode 1 1 venetian mode (up/down and slate rotation) 72 slats tilting full turn time this parameter defines the time necessary for slats to make full turn (180 degrees). available configuration parameters (data type is 2 byte dec): • default value 150 = 1,5 seconds • 0 tilting time disabled • 1 32767 = 0,01seconds 327,67 seconds note: if time set is too high, this will result that after full turn, shutter will start move up or down, for time remaining. 1 2 0 32767 150 from to description 0 0 tilting time disabled 1 32767 0,01seconds 327,67 seconds 73 slats position this parameter defines slats position after up/down movement through z wave or push buttons. available configuration parameters (data type is 1 byte dec): • default value 1 • 0 slats return to previously set position only in case of z wave control (not valid for limit switch positions). • 1 slats return to previously set position in case of z wave control, push button operation or when the lower limit switch is reached. 1 1 0 1 1 from to description 0 0 slats return to the previously set position only after being activated via the z wave gateway (hub) (not valid for limit switch positions) 1 1 slats return to the previously set position in case they were activated via the z wave gateway (hub), push button operation or when the lower limit switch is reached 74 motor moving up/down time this parameter defines shutter motor moving time of complete opening or complete closing. available configuration parameters (data type is 2 byte dec): • default value 0 • 0 – moving time disabled (working with limit switches) • 1 32767 = 0,1seconds 3276,7seconds after that time motor is stopped (relay goes to off state) note: important is that the reference position to manually set moving time is always shutter lower position! set parameter 74 to 0 and move the shutter (using up/down push buttons or main controller ui) to the lowest desired position. on this shutter position, set parameter 74 to time for complete opening or complete closing. at this point shutter can be moved up (open) for set time, but can't be moved down because this position is already set as lower shutter position. to change shutter lower position below already set (manual recalibration), parameter 74 must be set to 0 and repeat the procedure described above. in case shutter has limit switches, but anyhow you would like to limit opening/closing position by time, you can still do it. in case you put time that is longer that opening/closing real time limited by limit switches, shutter will stop at limit switch, but the module relay will switch off after define time, not by shutter limit switch. take in consideration that in this condition, the positioning with slider through ui will not show correct shutter position. 1 2 0 32767 0 from to description 0 0 moving time disabled (working with limit switches) 1 32676 0.1 seconds – 3276.7 seconds 78 forced shutter calibration by modifying the parameters setting from 0 to 1 a shutter enters the calibration mode. available configuration parameters (data type is 1 byte dec): • default value 0 • 1 start calibration process (when calibration process is finished, completing full cycle up, down and up, set the parameter 78 (forced shutter calibration) value back to 0. 1 1 0 1 0 from to description 0 1 start calibration process (when calibration process is finished, completing full cycle up, down and up, set the parameter 78 (forced shutter calibration) value back to 0. 110 temperature sensor offset settings set value is added or subtracted to actual measured value by sensor. available configuration parameters (data type is 2 byte dec): • default value 32536 • 32536 offset is 0.0 c • from 1 to 100 value from 0.1 °c to 10.0 °c is added to actual measured temperature. • from 1001 to 1100 value from 0.1 °c to 10.0 °c is subtracted to actual measured temperature. 1 2 0 32536 32536 from to description 1 100 where 1 stands for 0.1°c and 100 stands for 10.0°c added to the actual measurement. 1001 1100 where 1001 stands for 0.1°c and 1100 stands for 10.0°c subtracted from the actual measurement. 32536 32536 offset is 0.0 c 120 parameter no. 120 – temperature sensor reporting threshold if digital temperature sensor is connected, module reports measured temperature on temperature change defined by this parameter. available configuration parameters (data type is 1 byte dec): • default value 5 = 0,5°c • 0 reporting disabled • 1 127 = 0,1°c 12,7°c, step is 0,1°c 1 1 0 127 5 from to description 0 0 reporting disabled 1 127 where 1 stands for 0.1°c and 127 stands for 12.7°c. texts
