- Name
- Shutter
- Brand
- TechniSat
- Features
- Feature Values Neutral Wire Required
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1900
- Categories
- Energy Meters, Window Covering
- Product id
- 0x1A93
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED, S2_ACCESS_CONTROL
- Device type
- Window Covering - Endpoint Aware
- Oem version
- HW: 6 FW: 2.00
- Library type
- SLAVE_ENHANCED_232
- Product line
- Smart Home
- Supports nwi
- Yes
- Installer icon
- 0x1900
- Z wave version
- 6.82.00
- Frequency plans
- EU: 869.85MHz, 868.40MHz
- Manufacturer id
- 0x0299
- Product type id
- 0x0005
- Long description
- Designed as a drop-in replacement for your shutter wall switch from leading brand manufacturers, TechniSat's Shutter-Switch integrates your wall switch into the Smart Home future. Featuring Z-Wave SmartStart and S2 security for easy installation and secure operation, your shutter switch can now be controlled from your Smart Home as well. ● Full manual operation ● can trigger central scenes via multiple button clicks ● Short circuit and overload protection monitoring.
- Hardware platform
- ZM5101
- Short description
- The smart, wall mounted shutter switch is suitable for controlling AC motors of roller shutters in a Z-Wave network and can also be switched manually by hand.
- Product identifier
- 0x00/9496
- Countries / regions
- European Union
- Supports smart start
- Yes
- Certification number
- ZC10-20026858
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4
- Controlled command classes
- Identifier Name Key Version COMMAND_CLASS_BASIC_V2
- Supported notification types
- Notification Type Event / State Power Management
- Supported / controlled meter types
- Meter Type Rate Type Description Electric meter
- Value updatable by consumer by rf association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile Description 1
- From to description 0 0 setting this parameter to 0 will disable central scene notifications for multiple (2x 5x) button presses. 1 1 setting this parameter to 1 will enable central scene notifications for multiple (2x 5x) button presses. 2 parameter 2 interval of current wattage meter reports in 10 seconds increments. 1 2 0 8640 3 from to description 0 0 disable unsolicited meter reports of current wattage. 3 8640 interval of current wattage meter unsolicited reports in 10s increments (30 seconds 1 day) 3 parameter 3 interval of active energy meter reports in minutes. 1 2 0 30240 60 from to description 0 0 disable unsolicited meter reports of active energy. 10 30240 interval of active energy meter unsolicited reports in minutes (10 minutes 3 weeks) 4 parameter 4 manual shutter calibration shutter will move up, down and up again 1 1 0 1 0 from to description 0 1 setting this parameter to 1 will start a manual shutter calibration. texts
- ID Description Value 8
