- Name
- A19 LED BULB RGBW
- Brand
- Aibase
- Features
- Feature Values Communications Protocol
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x0600
- Categories
- All Lighting Devices, Dimming Lighting Devices
- Product id
- 0x0003
- Device type
- Light Dimmer Switch
- Oem version
- HW: 0 FW: 2.00
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Installer icon
- 0x0600
- Z wave version
- 6.51.09
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x0384
- Product type id
- 0x0003
- Long description
- AIBASE RGBW Bulb is a switch multilevel device based on Z-Wave enhanced 232 slave libraryof V6.51.09. RGBW Bulb has 5 main color channels available for you to adjust: Warm white , Cold white,Red,Green and Blue. RGBW Bulb can be included and operated in any Z‐Wave network with other Z‐Wave certifieddevices from other manufacturers and/or other applications. All non‐battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network. The RGBW Bulb is a security Z-Wave device(S0), so a security enabled controller is needed for take full advantage of all functionally for the LED Bulb. It also supports the Over The Air (OTA) feature for the product’s firmware upgrade.
- Hardware platform
- ZM5101
- Short description
- ✓ Standard form factor and appearance of the light bulb with 800 lm output ✓ RGBW: dimmable from 5% to 100%, tunable from 1800K to 6500K, and 16 million colors ✓ Possible to be included in groups, scenes, or schedules ✓ Suitable for indoor lighting: Corridors, Bedroom, Living Room, etc.
- Product identifier
- HA-ZW-5AQG
- Countries / regions
- United States of America
- Certification number
- ZC10-18056115
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_POWERLEVEL
- Value manufacturer proprietary protocol firmware updatable value updatable by manufacturer association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
- From to description 128 127 it is used to get the internal temperture of the bulb. 255 resetting this parameter is used to reset to factory configuration and remove the node from the z wave network, or to reset configuration parameter to their default value. 0 4 0 0 0 from to description 2004318072 2004318072 reset to factory configuration and removed the node from the z wave network. 2013265920 2013265920 reset configuration parameter to default value. texts
- ID Description Value 1
