Shutter Control

Name

Shutter Control

Brand

Climax Technology

Features

Feature Values Firmware Updatable

Documents

Category Description File Manual_Primary_Lang

Role type

ROLE_TYPE_SLAVE_ALWAYS_ON

User icon

0x1A00

Categories

Motor Control, Window Covering

Product id

0x0005

S2 classes

S2_UNAUTHENTICATED

Device type

Window Covering - Pos/End Aware

Oem version

HW: 255 FW: 4.01

Library type

SLAVE_ENHANCED_232

Supports nwi

Yes

Installer icon

0x1A00

Z wave version

6.81.01

Frequency plans

EU: 869.85MHz, 868.40MHz

Manufacturer id

0x018E

Product type id

0x0004

Long description

The SCM-2ZW is a Z-Wave roller shutter control that provides remote operation of roller shutters for home automation and security purposes. Automatically or remotely roll up, down or stop mid-way, the SCM-2ZW is directly connected to and controls motorized window treatments, interior and exterior shades and blinds, projection screen, and garage door or driveway gate of your home. With SCM-2ZW, all roller shutters in the house can be configured to automatically open or close according to preset schedules and scenarios.

Hardware platform

ZM5202

Short description

The SCM-2ZW is a Z-Wave roller shutter control that provides remote operation of roller shutters for home automation and security purposes.

Product identifier

SCM-2ZW

Countries / regions

European Union

Certification number

ZC10-19036397

Radio range z wave (m)

40

Configuration parameters

Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1

Supports explorer frames

Yes

Supported command classes

Identifier Name Key Version COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4

Value updatable by consumer by rf window covering control features value supports up/down motion association groups

Group Number Maximum Nodes Supported End Point ID Description 1

From to description 0 255 the ranges from 0 to 255 seconds. 2 close time setting for parameter 2, users can set the close time (from up to down) time to a value that ranges from 0 to 255 seconds. 0 2 0 0 240 from to description 0 255 the ranges from 0 to 255 seconds. 3 current position for parameter 3, users can set the current position to a value that ranges from 0% to 99%. 0 2 0 0 99 from to description 0 99 the ranges from 0% to 99%. texts

ID Description Value 1
