- Name
- Plug in Dimmer Switch
- Brand
- Dragon Tech Industrial, Ltd.
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- Categories
- All Lighting Devices, Dimming Lighting Devices
- Product id
- 0x3032
- Device type
- Light Dimmer Switch
- Oem version
- HW: 255
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Z wave version
- 6.51.02
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x0184
- Product type id
- 0x4744
- Long description
- PD-100 Plug in Dimmer Module • Works with any AC operated lamps with incandescent and dimmable florescent(CFL) or LED light bulbs • ON/OFF status and location LED indicator • Can be controlled wirelessly or manually • Plug and play, simple setup • Lightweight and compact. • Grounded 3-pin AC power plug to enhance safety • Over-The-Air firmware upgrade available with compatible gateway, Z-Wave static controller, PC and software • Z-Wave 500 Series module inside • Internal resettable fuse to protect from surge current • Manual reset capability • Adjustable dimming rate
- Hardware platform
- ZM5202
- Short description
- PD-100 Plug in Dimmer Module - Remotely controls On, Off, or Dim levels of the connected device. - Second wall AC outlet remains free - Works with any gateway supporting Z-Wave - Functions as a Z-Wave signal repeater
- Association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
- Product identifier
- PD-100
- Countries / regions
- United States of America
- Certification number
- ZC10-14090002
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 10
- Supports explorer frames
- Yes
- From to description 1 255 for every unit increase or descrease, the duration is increased or decreased by 10msec. higher the number, slower the duration it takes to adjust the dim level. 3 led backlight for key switch this parameter controls the operation of the led backlight in conjunction with the operating state of the switch. 0 1 0 0 0 from to description 1 1 led indicator turns on when the connected appliance is on. led indciator will be off when the connected appliance is off. 0 0 when the connected appliance is off, the led indicator will be on. when the connected appliance is on, the led indicator will be off. 2 2 key switch led backlight is always off. 9 dimming steps indicates the number of steps the lighting brightness level will change as timer runs out when pressing the rocker switch up or down. 0 1 0 0 1 from to description 1 99 set preferred increments of levels. higher the number the faster the device will change brightness level. texts
- ID Description Value 1
