- Name
- Z-Wave Long Range Contact Sensor
- Brand
- Ecolink
- Texts
- ID Description Value 8
- Features
- Feature Values Battery Quantity
- Documents
- Category File Manual_English
- Role type
- ROLE_TYPE_END_NODE_SLEEPING_REPORTING
- User icon
- 0x0C07
- Categories
- Sensors, Security Systems
- Identifier
- DWZW8-ECO
- Product id
- 0x07EB
- S2 classes
- S2_AUTHENTICATED, S2_UNAUTHENTICATED
- Brand owner
- Universal Electronics Inc
- Description
- The Ecolink Contact Sensor features a small, low profile, stylish design that is easy to mount and blends in with any residential décor. The sensor monitors the opening and closing of doors, windows or other contact points. The sensor supports Z-Wave Long Range and Z-Wave Plus®, features S2 encryption, and is designed for indoor use only. There are a few methods to add a device to a Z-Wave® network: SmartStart. The contact sensor also compatible with Z-Wave 300, 500 and 700 series panels.
- Device type
- Notification Sensor DT
- Oem version
- HW: 01 FW: 01.02:02.03
- Product url
- https://discoverecolink.com/product/z-wave-long-range-door-window-sensor/
- Library type
- END_NODE_ENHANCED_232
- Product line
- Z-Wave Long Range
- Supports nwi
- Yes
- Installer icon
- 0x0C07
- Z wave version
- 7.19.3
- Frequency plans
- US_LR: 912.00MHz, 920.00MHz, US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x014A
- Product type id
- 0x0004
- Hardware platform
- EFR32ZG23B
- Short description
- This is a compact form factor indoor Z-Wave contact sensor for security and home automation applications for use on doors and windows.
- Countries / regions
- Canada, United States of America
- Supports smart start
- Yes
- Certification number
- ZC14-25120563
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Flag Advanced Size Min Value Max Value Default Value 1
- Supports explorer frames
- Yes
- Radio range z wave lr (m)
- 400
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_ASSOCIATION_V2
- Supported notification types
- Notification Type Event / State Home Security
- Value 1 battery battery type value cr2450 color value white firmware updatable value updatable by manufacturer representative association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile 1
