- Name
- Chime+Siren
- Brand
- Ecolink
- Features
- Feature Values Color
- Documents
- Category Description File Image_Product_Supplemental_3
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x2202
- Categories
- All Lighting Devices, On/Off Switches/Devices, Security Add-Ons, Security Systems
- Product id
- 0x3975
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Sound Switch DT
- Oem version
- HW: 1 FW: 2.00:01.10
- Library type
- SLAVE_ENHANCED_232
- Product line
- Z-Wave
- Supports nwi
- Yes
- Installer icon
- 0x2200
- Z wave version
- 7.13.6
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x014A
- Product type id
- 0x0007
- Long description
- The Ecolink Chime+Sirenis a Z-Wave Plus enabled device designed to smoothly integrate into a Z-Wave Plus home automation network. This device will sound a siren or chime or doorbell on the automations created by the controller. This easy to install Security siren has 30 different build in sound effects for different notifications and sirens. It has a built in 24 hour battery back up in case of power outages or when used in a security system to prevent tampering to turn sirens off. It has a microSD slot to allow custom sounds to be loaded onto the device.
- Hardware platform
- ZGM130
- Short description
- The Ecolink Chime+Siren has 30 built in sound effects for alarms, notifications and doorbells. Load in your custom sounds via the microSD.
- Product identifier
- ISZW7-ECO
- Countries / regions
- United States of America
- Supports smart start
- Yes
- Certification number
- ZC12-20100128
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Flag Advanced Size Min Value Max Value Default Value Parameter Values 3
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_SOUND_SWITCH
- Supported notification types
- Notification Type Event / State Power Management
- Value white association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile Description 1
- From to description 1 0 enabled 0 0 disabled 2 heartbeat notification timing seconds between automatic battery reports. 2 yes 4 120 86400 3600 from to description 120 86400 seconds between automatic battery reports. 4 sound volume sound volume as a percentage for non emergency sounds (see configuration parameter #6). 1 to 100, whereas 0 is mute, and 255 is restore last volume before mute. 2 1 0 100 50 from to description 0 100 sound volume as a percentage for non emergency sounds 1 default sound map basic set of 0x ff to play the sound number set here. e.g. a 1 is siren and a 5 is a chime. 2 1 1 100 5 from to description 1 100 different types of sounds 6 emergency sound volume adjustable enable intrusion/smoke/co siren volume adjustable and mutable. 0 is disabled (default). 1 is enabled. 3 yes 1 0 1 0 from to description 1 0 enable alarm type sounds volume adjustments 0 0 disabled alarm type sounds volume adjustments texts
- ID Description Value 4
