- Name
- IQ Siren 8
- Brand
- Qolsys
- Texts
- ID Description Value 8
- Features
- Feature Values Battery Quantity
- Documents
- Category File Description Installer_Guide
- Role type
- ROLE_TYPE_END_NODE_ALWAYS_ON
- User icon
- 0x0F00
- Categories
- On/Off Switches/Devices
- Identifier
- IQZWSRN
- Product id
- 0x0002
- S2 classes
- S2_AUTHENTICATED, S2_UNAUTHENTICATED
- Brand owner
- Johnson Controls
- Description
- It plugs into any standard outlet, acts as a repeater in the Z-Wave network (when paired as Z-Wave Plus), has a rechargeable back up battery and LED lights that strobe when the siren is triggered.
- Device type
- Binary Switch DT
- Oem version
- HW: 172 FW: 01.01
- Product url
- http://dealers.qolsys.com
- Library type
- END_NODE_ENHANCED_232
- Product line
- Z-Wave Product Line
- Supports nwi
- Yes
- Installer icon
- 0x0F00
- Z wave version
- 7.23.2
- Frequency plans
- US: 916.00MHz, 908.40MHz, US_LR: 912.00MHz, 920.00MHz
- Manufacturer id
- 0x012A
- Product type id
- 0x0003
- Hardware platform
- EFR32ZG23A
- Short description
- The IQ Siren 8 is a wireless Z-Wave Plus 800 series device that allows you to have additional sirens placed throughout the home.
- Countries / regions
- Argentina, Bahamas, Barbados, Bermuda, Bolivia, British Virgin Islands, Canada, Cayman Islands, Colombia, Guatemala, Haiti, Honduras, Jamaica, Mexico, Panama, Saint Kitts and Nevis, Suriname, Trinidad and Tobago, Turks and Caicos Islands, United States of America
- Supports smart start
- Yes
- Certification number
- ZC14-26030586
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value 1
- Supports explorer frames
- Yes
- Radio range z wave lr (m)
- 400
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_ASSOCIATION_V2
- Supported notification types
- Notification Type Event / State Power Management
- Value 1 battery type value lithium rechargeable battery firmware updatable value updatable by consumer by rf association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile 1
