- Name
- UltraPro Z-Wave Plus In-Wall Paddle Switch 800S
- Brand
- UltraPro
- Texts
- ID Description Value 8
- Features
- Feature Values Color
- Documents
- Category File Manual_English
- Role type
- ROLE_TYPE_END_NODE_ALWAYS_ON
- User icon
- 0x0700
- Categories
- All Lighting Devices, On/Off Switches/Devices, Lighting Accessories
- Identifier
- ZWN4017
- Product id
- 0x3534
- S2 classes
- S2_AUTHENTICATED, S2_UNAUTHENTICATED
- Brand owner
- JASCO
- Description
- Z-Wave Long Range On/Off Switch, Experience the latest generation of Z-Wave® smart controls for in-wall configurations with toggle-style on/off to accommodate any home.
- Device type
- Binary Switch DT
- Oem version
- HW: 01 FW: 00.03
- Library type
- END_NODE_ENHANCED_232
- Product line
- Line A
- Supports nwi
- Yes
- Installer icon
- 0x0704
- Z wave version
- 7.23.1
- Frequency plans
- US: 916.00MHz, 908.40MHz, US_LR: 912.00MHz, 920.00MHz
- Manufacturer id
- 0x0063
- Product type id
- 0x4952
- Hardware platform
- EFR32ZG23A
- Short description
- Z-Wave Long Range On/Off Switch, Longer distance, more stable network, reliable control of your lighting.
- Countries / regions
- Canada, Mexico, United States of America
- Supports smart start
- Yes
- Certification number
- ZC14-26040608
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value 3
- Supports explorer frames
- Yes
- Radio range z wave lr (m)
- 400
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_BASIC_V2
- Value white electric load type value incandescent led inductive (e.g. motor) firmware updatable value updatable by consumer by rf switch load capacity current value 15 a association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile 1
