- Name
- Smart On/Off Switch
- Brand
- Inovelli
- Texts
- ID Description Value 8
- Features
- Feature Values Electric Load Type
- Documents
- Category File Manual_English
- Role type
- ROLE_TYPE_END_NODE_ALWAYS_ON
- User icon
- 0x0600
- Categories
- All Lighting Devices, On/Off Switches/Devices
- Identifier
- VZW30-SN
- Product id
- 0x0001
- S2 classes
- S2_AUTHENTICATED, S2_UNAUTHENTICATED
- Brand owner
- Inovelli
- Description
- The Inovelli Z-Wave® On/Off Smart Switch has a built-in humidity sensor that automatically controls lights, fans, outlets, and other general-purpose loads to keep your space comfortable and dry. Perfect for bathrooms, laundry rooms, and basements, it can kick on a fan when humidity spikes and turn things back off when the air clears. You’ll also get Inovelli’s signature LED bar for at-a-glance status and customizable notifications, plus multi-tap scene control so one switch can trigger whole-home automations, from “shower time” lighting to “goodnight” scenes.
- Device type
- Multilevel Switch DT
- Oem version
- HW: 01 FW: 02.01
- Library type
- END_NODE_ENHANCED_232
- Product line
- Red Series
- Supports nwi
- Yes
- Installer icon
- 0x0600
- Z wave version
- 7.24.2
- Frequency plans
- US: 916.00MHz, 908.40MHz, US_LR: 912.00MHz, 920.00MHz
- Manufacturer id
- 0x031E
- Product type id
- 0x0018
- Hardware platform
- EFR32ZG23A
- Short description
- Introducing the Z-Wave® On/Off Switch with humidity detection, Multi-Tap Scene Control and LED Notifications powered by Inovelli.
- Countries / regions
- Canada, United States of America
- Supports smart start
- Yes
- Certification number
- ZC14-26020581
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value 1
- Supports explorer frames
- Yes
- Radio range z wave lr (m)
- 400
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_ASSOCIATION_V2
- Supported multilevel sensors
- Multilevel Sensor Type Air temperature
- Supported / controlled meter types
- Meter Type Rate Type Electric meter
- Value incandescent fluorescent mlv (magnetic) elv (electronic) led inductive (e.g. motor) firmware updatable value updatable by consumer by rf neutral wire required value 1 switch load capacity volt ampere value 1800 switch load capacity watts value 1800 switch type value decorator paddle push with indicator z wave scene type value central scene association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile 1
