- Name
- IQ Smart Dimmer
- Brand
- Qolsys
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x0604
- Categories
- All Lighting Devices, Dimming Lighting Devices, On/Off Switches/Devices
- Product id
- 0xFF0D
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Multilevel Switch
- Oem version
- HW: 1 FW: 1.00
- Library type
- SLAVE_ENHANCED_232
- Product line
- Line A
- Supports nwi
- Yes
- Installer icon
- 0x0600
- Z wave version
- 7.13.6
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x012A
- Product type id
- 0xFF00
- Long description
- The IQ Smart Dimmer can be used to turn any outlet into a smart outlet to turn lamps On, Off, or control dimming of any lamps with dimmable light bulbs. Each Z-Wave ™ device also serves as a repeater in the Z-Wave network, extending and improving the mesh network in the installed location. The IQ Smart Dimmer is a Z-Wave Plus ™ certified device and includes S2 security and SmartStart. You can now add this device securely and with ease using QR code on the box or device.
- Hardware platform
- ZGM130
- Short description
- The IQ Smart Dimmer can be used to turn any outlet into a smart outlet to turn lamps On, Off, or control dimming of any lamps with dimmable light bulbs. Each Z-Wave device also serves as a repeater in the Z-Wave ™ network, extending and improving the mesh network in the installed location.
- Association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile Description 3
- Product identifier
- QZ2142-840
- Countries / regions
- United States of America, Canada, Mexico
- Supports smart start
- Yes
- Certification number
- ZC12-22040337
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 3
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_CONFIGURATION_V4
- From to description 0 0 default 1 65535 1 – 65535 (minutes) 5 auto turn on timer auto turn on timer 2 4 0 65535 0 from to description 0 0 default 1 65535 1 – 65535 (minutes) 10 multilevel minimum value can be set multilevel minimum value can be set（local button）> this should apply to both for local or z wave operation parameter=10，size=1，value=0 disable value=1 . . value=99 default = 1 2 1 0 99 1 from to description 0 0 disabled 1 99 minimum multilevel level 8 restores state after power failure restores state after power failure parameter=8，size=1，value=0 output off value=1 output on value=2 out put the state after power default =2 2 1 0 2 2 from to description 1 1 output on 2 2 the state before a power outage 0 0 output off 11 multilevel maximum value can be set multilevel maximum value can be set（local button）> this should apply to both for local or z wave operation parameter=11，size=1，value=0 disable value=1 . . value=100 not accepted by hub default = 99 2 1 0 100 99 from to description 1 100 maximum multilevel level 0 0 disabled 24 led indicator brightness led indicator brightness parameter=24，size=1，value=0 bright (100%) value=1 medium (60%) value=2 low (30%) default =1 2 1 0 2 1 from to description 0 0 bright (100%) 1 1 medium (60%) 2 2 low (30%) 23 led indicator color led indicator color parameter=23，size=1，value=0 white value=1 blue value=2 green value=3 red default = 1 2 1 0 3 1 from to description 0 0 white 1 1 blue 2 2 green 3 3 red 25 single tap behavior single tap behavior: when switch is off and press upper paddle 1 time, switch turns on to x brightness （local button） parameter=25，size=1， value = 0 last brightness level value = 1 custom value set in parameter 18 value = 2 maximum brightness set in parameter 11 value = 3 full 100% brightness default = 0 2 1 0 3 0 from to description 0 0 last brightness level 1 1 custom value set in parameter 18 2 2 maximum brightness set in parameter 11 3 3 full 100% brightness 2 led indicator parameter=2，size=1，value=0 on when off and off when on value=1 on when on and off when off value=2 always off value=3 always on default =0 2 1 0 3 0 from to description 0 0 output and the led are in the different state. 1 1 output and the led are in the same state. 2 2 led always off 3 3 led always on 9 ramp rate ramp rate（local button + z wave）> change to local and z wave like in the latest zen30 firmware, also applies to any multilevel changes (so there should be soft transition between 20 and 80% brightness if changed from the hub for example) parameter=9，size=1, value=1 from 0x63 to 0x00 or from 0x00 to 0x63 need 1s value=2 from 0x63 to 0x00 or from 0x00 to 0x63 need 2s . . value=99 from 0x63 to 0x00 or from 0x00 to 0x63 need 99s default = 1 2 1 1 99 1 from to description 1 99 ramp rate in seconds texts
