- Name
- Roller Shutter Multi Level Switch
- Brand
- Good Way Technology, Co., Ltd
- Features
- Feature Values Window Covering Control Features
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1A00
- Categories
- Motor Control, Window Covering
- Product id
- 0x0014
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Window Covering - Pos/End Aware
- Oem version
- HW: 1 FW: 2.00
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Installer icon
- 0x1A00
- Z wave version
- 6.81.00
- Frequency plans
- EU: 869.85MHz, 868.40MHz
- Manufacturer id
- 0x0068
- Product type id
- 0x0003
- Long description
- Z-Wave Roller Shutter Controller is an ideal for the remotely electric motor controller. It is used to control the motors of rollers, shades, blinds, venetian blinds and similar sun shade, which are single phase AC powered. The module can be controlled either through a Z-Wave network or through the wall switch, and measures power consumption of motor.
- Hardware platform
- ZM5101
- Short description
- Z-Wave Roller Shutter Controller is an ideal for the remotely electric motor controller
- Product identifier
- Roller Shutter/TD11010
- Countries / regions
- European Union
- Supports smart start
- Yes
- Certification number
- ZC10-18036063
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 4
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4
- Supported / controlled meter types
- Meter Type Rate Type Description Electric meter
- Value supports curtains supports vertical blinds supports up/down motion supports rotation motion supported meter type value electric energy firmware updatable value updatable by manufacturer association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
- From to description 0 32767 delay time 2 external switch protection external switch protection: 0: enable external switch 1: disable external switch 0 1 0 0 0 from to description 0 1 external switch protection 6 set the angle of blinds angles of blinds 0：0∘ 1：30∘ 2：60∘ 3：90∘ 4：120∘ 5：150∘ 6：180∘ 0 1 0 0 0 from to description 0 6 set the angle of blinds 8 set the delay time to start the motor up to the blade set the delay time to start the motor up to the blade: 0: no offset time 1 127: 0.1 12.7 sec 0 1 0 0 0 from to description 0 127 delay time 9 set the delay time to start the motor down to the blade set the delay time to start the motor down to the blade. 0: no offset time 1 127: 0.1 – 12.7 sec 0 1 0 0 0 from to description 0 127 delay time 5 set the operation mode set the operation mode: 0: roller shutter 1: venetian (up/down and slate rotation) 0 1 0 0 0 from to description 0 1 set the operation mode 11 set the time interval of reporting watts in seconds set the time interval of reporting watts in seconds. 0: disable 60 32767: 60 32767sec 0 2 0 0 300 from to description 0 0 disable 60 32767 times 1 positioning calibration positioning calibration: 0: disable 1: executing calibration 0 1 0 0 0 from to description 0 1 positioning calibration 3 when the door is opened, set the delay time for automatic closing. when the door is opened, set the delay time for automatic closing. 0: disable automatic closing 1 32767: the door will be closed automatically in 1 32767sec 0 2 0 0 0 from to description 0 32767 delay time 10 set the power changed percentage to send the power report set the power changed percentage to send the power report. 0: disabled 1 100: 1% 100% 0 1 0 0 0 from to description 0 100 changed range texts
