- Name
- Thermostat Control Panel
- Brand
- Jintaobao
- Features
- Feature Values Firmware Updatable
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1200
- Categories
- Thermostats
- Product id
- 0x0003
- Device type
- Thermostat - HVAC
- Oem version
- HW: 33 FW: 1.01:01.01
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Installer icon
- 0x1200
- Z wave version
- 6.51.09
- Frequency plans
- EU: 869.85MHz, 868.40MHz
- Manufacturer id
- 0x015A
- Product type id
- 0x3005
- Long description
- The product is a Z-Wave enabled room thermostat support control cool/heat/fan climate in Z-Wave system. The desired temperature in the room can be set locally using the button on the front of the unit. It works in the same way as a normal room thermostat with hard wired to the heating source; meanwhile control is achieved using Z-Wave wireless signals also. This enables you to control heating times and schedule zone heating. This product can be operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers. All non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network.
- Hardware platform
- ZM5202
- Short description
- The product is a Z-Wave enabled room thermostat support control cool/heat/fan climate in Z-Wave system. The desired temperature in the room can be set locally using the button on the front of the unit.
- Product identifier
- JTB-3005-03
- Countries / regions
- European Union
- Certification number
- ZC10-17105800
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_SENSOR_MULTILEVEL_V5
- Supported multilevel sensors
- Multilevel Sensor Type Air temperature
- From to description 128 128 synchronization 0 0 no synchronization 2 inner master mcu communication address should setting same as inner master mcu configuration. 0 1 0 0 1 from to description 1 127 should same as inner master mcu configuration. texts
- ID Description Value 5
- Value updatable by consumer by rf switch load capacity current value 1 switch load capacity volt ampere value 220 switch load capacity watts value 200 neutral wire required sensors value air temperature thermostat hvac systems supported value simple relay heat only cool only single stage thermostat modes value heat cool resume fan only energy save heat energy save cool thermostat power source value mains powered (120 v/240 v) association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
