- Name
- Smart Button
- Brand
- LG U+
- Texts
- ID Description Value 23
- Features
- Feature Values Battery Quantity
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_SLEEPING_REPORTING
- User icon
- 0x1600
- Categories
- All Lighting Devices, All Controllers, Handheld Controller, Lighting Accessories
- Product id
- 0x0001
- S2 classes
- S2_UNAUTHENTICATED
- Device type
- Wall Controller
- Oem version
- HW: 1 FW: 39.40
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Installer icon
- 0x1600
- Z wave version
- 6.71.01
- Frequency plans
- KR: 920.90MHz, 921.70MHz, 923.10MHz
- Manufacturer id
- 0x014d
- Product type id
- 0x0054
- Long description
- Smart Button enables prompt access to the pre-defined operations such as turning all lights off, sending emergency notification to family members, and welcoming guests and so on.
- Hardware platform
- ZM5101
- Short description
- Smart Button is a button device which extends the world of Z-Wave network.
- Product identifier
- IBDK-01
- Countries / regions
- Republic of Korea
- Certification number
- ZC10-17095784
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4
- Controlled command classes
- Identifier Name Key Version COMMAND_CLASS_SUPERVISION
- Value 2 battery type value aaa firmware updatable value updatable by consumer by rf association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
