- Name
- UPowerSwitch
- Brand
- LG U+
- Features
- Feature Values Color
- Is flirs
- Yes
- Documents
- Category Description File Manual_English
- Role type
- ROLE_TYPE_SLAVE_SLEEPING_LISTENING
- User icon
- 0x0700
- Categories
- All Lighting Devices, On/Off Switches/Devices
- Product id
- 0x0002
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Binary Switch
- Oem version
- HW: 1 FW: 10.11
- Library type
- SLAVE_ENHANCED_232
- Product line
- LG U+ IOT Power Switch
- Supports nwi
- Yes
- Installer icon
- 0x0700
- Z wave version
- 7.11.0
- Frequency plans
- KR: 920.90MHz, 921.70MHz, 923.10MHz
- Manufacturer id
- 0x0357
- Product type id
- 0x0058
- Long description
- This is a smart light switch. It has 2 buttons, using 1 wire AC line. You can control the light from the remote or manually. Input AC power:220V.
- Hardware platform
- ZGM130
- Short description
- This is a smart light switch.
- Product identifier
- UPowerSwitch
- Countries / regions
- Republic of Korea
- Supports smart start
- Yes
- Certification number
- ZC12-19100016
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_CONFIGURATION_V4
- Supported multilevel sensors
- Multilevel Sensor Type Air temperature
- Supported notification types
- Notification Type Event / State Heat Alarm
- From to description 60 3600 setting a value in this range means to set the period value of the report. for example, 600 means that the reporting period is 600 seconds. texts
- ID Description Value 8
- Value white electric load type value incandescent fluorescent led firmware updatable value updatable by manufacturer representative outdoor use switch load capacity current value 3 a switch load capacity volt ampere value ac220 v switch load capacity watts value 600 w switch type value push button with indicator association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile Description 1
