OCTAN Remote — NodOn — Off Screen Space

Off Screen Space

OCTAN Remote

NodOn · Remote

OCTAN Remote

View all NodOn products

Connectivity: Z-WaveCategory: Remote

Z-Wave

The OCTAN Remote NodOn® controls any compatible receivers Z-Wave® or Z-Wave Plus®, such as the Smart Plug NodOn®. It can address, directly, up to 4 groups of 8 devices and sent up to 16 different scenes to a Home Automation Gateway. This controller can operate on its own (“Standalone” Mode) or as gateway’s assistant (“Gateway” Mode). The product integrates a LED, which give an intuitive feedback for each operation you perform. Based on an innovative technology, the OCTAN Remote NodOn® is only powered with a CR2032 battery, offering 2 years’ autonomy. A magnetic wall support is included with your OCTAN Remote NodOn®, which allow you to easily install and move it. This support can be screwed or fixed by adhesive bonding. The remote control embeds a small magnet, allowing fixing it on its wall support or on any metallic surface (fridge door, heater, etc.). The OCTAN Remote NodOn® is based on brand new 500 series Z-Wave® module from Sigma Designs®, and supports all the new features of Z-Wave Plus® standard: Longer range (up to 40 meters indoor), lower power consumption, higher data rate transmission, and many more new features.

Want to buy adds it to your wish list and follows NodOn for updates. I own it adds it to your collection.

Compare

vs Competitor ▾

Connectivity

Z-Wave

Firmware

Current version 02

Specifications

Overview

Company: NodOn
Category: Remote
Device type: Remote Control - Multi Purpose

Connectivity

Standard / protocol: Z-Wave
Connectivity: Z-Wave
Transport: Z-Wave
Spec version: 6.51.06
Z-Wave frequency: EU: 869.85MHz, 868.40MHz

Certification & compliance

Certificate ID

Community tags

Be the first to tag this page — tags appear right away. Try a theme, capability, or subject (e.g. WWII, heist, slow burn, time travel, A24).

More specs

Name: OCTAN Remote
Brand: NodOn
Features: Feature Values Battery Quantity
Documents: Category Description File Manual_Primary_Lang
Role type: ROLE_TYPE_CONTROLLER_PORTABLE
User icon: 0x0A00
Categories: All Controllers, Handheld Controller
Product id: 0x0001
Device type: Remote Control - Multi Purpose
Oem version: HW: 2 FW: 3.03:01.05
Library type: CONTROLLER_PORTABLE
Supports nwi: Yes
Installer icon: 0x0A00
Z wave version: 6.51.06
Frequency plans: US: 916.00MHz, 908.40MHz
Manufacturer id: 0x0165
Product type id: 0x0002
Long description: The OCTAN Remote NodOn® controls any compatible receivers Z-Wave® or Z-Wave Plus®, such as the Smart Plug NodOn®. It can address, directly, up to 4 groups of 8 devices and sent up to 16 different scenes to a Home Automation Gateway. This controller can operate on its own (“Standalone” Mode) or as gateway’s assistant (“Gateway” Mode). The product integrates a LED, which give an intuitive feedback for each operation you perform. Based on an innovative technology, the OCTAN Remote NodOn® is only powered with a CR2032 battery, offering 2 years’ autonomy. A magnetic wall support is included with your OCTAN Remote NodOn®, which allow you to easily install and move it. This support can be screwed or fixed by adhesive bonding. The remote control embeds a small magnet, allowing fixing it on its wall support or on any metallic surface (fridge door, heater, etc.). The OCTAN Remote NodOn® is based on brand new 500 series Z-Wave® module from Sigma Designs®, and supports all the new features of Z-Wave Plus® standard: Longer range (up to 40 meters indoor), lower power consumption, higher data rate transmission, and many more new features.
Hardware platform: ZM5202
Short description: The OCTAN Remote NodOn® controls any compatible receivers Z-Wave® or Z-Wave Plus®. It can address, directly, up to 4 groups of 8 devices and sent up to 16 different scenes to a Home Automation Gateway.
Product identifier: CRC-3-1-0X
Countries / regions: United States of America
Certification number: ZC10-16085200
Radio range z wave (m): 40
Configuration parameters: Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
Supports explorer frames: Yes
Controlled command classes: Identifier Name Key Version COMMAND_CLASS_SWITCH_ALL
Value 1 battery type value cr2032 color value white association groups: Group Number Maximum Nodes Supported End Point ID Description 1

From to description 0 0 scene. product sends “central scene notification” commands or “scene activation” commands. 1 1 mono. button 1 is not paired with button 3. 2 2 duo. button 1 is paired with button 3. 2 buttons 2&4 profile this parameter configures the behavior of the buttons 2 and 4 when the product is in “gateway" mode. 0 1 0 0 0 from to description 0 0 scene. product sends “central scene notification” commands or “scene activation” commands. 1 1 mono. button 1 is not paired with button 3. 2 2 duo. button 1 is paired with button 3. 3 scene type this parameter configures the type of command sent when the product is in “gateway centric mode”, with buttons profile configuration set in scene. we strongly advise you to use « central scene », which is more user friendly. however, some home automation gateways don’t support « central scene » yet, then you can still use the previous standard « scene activation ». the user interface of your gateway will then allow you to set up scenes. note: if parameter n°1 or n°2 is not set in scene, then this parameter is ignored. 0 1 0 0 0 from to description 0 0 use “central scene” commands. 1 1 use “scene activation” commands. 4 button 1 configuration this parameter configures the behavior of the button 1 in “gateway" mode, when set in mono (refers parameter n°1 – buttons 1&3 profile) note: if parameter n°1 is not set in mono, then this parameter is ignored. 0 1 0 0 0 from to description 0 0 single press sends “basic set” command to associated devices in group 2. 1 1 single press sends broadcast “switch all on” command. 2 2 single press sends broadcast “switch all off” command. 5 button 2 configuration this parameter configures the behavior of the button 2 in “gateway" mode, when set in mono (refers parameter n°1 – buttons 2&4 profile) note: if parameter n°2 is not set in mono, then this parameter is ignored. 0 1 0 0 0 from to description 0 0 single press sends “basic set” command to associated devices in group 3. 1 1 single press sends broadcast “switch all on” command. 2 2 single press sends broadcast “switch all off” command. 6 button 3 configuration this parameter configures the behavior of the button 3 in “gateway" mode, when set in mono (refers parameter n°1 – buttons 1&3 profile) note: if parameter n°1 is not set in mono, then this parameter is ignored. 0 1 0 0 0 from to description 0 0 single press sends “basic set” command to associated devices in group 4. 1 1 single press sends broadcast “switch all on” command. 2 2 single press sends broadcast “switch all off” command. 7 button 4 configuration this parameter configures the behavior of the button 4 in “gateway" mode, when set in mono (refers parameter n°1 – buttons 2&4 profile) note: if parameter n°2 is not set in mono, then this parameter is ignored. 0 1 0 0 0 from to description 0 0 single press sends “basic set” command to associated devices in group 5. 1 1 single press sends broadcast “switch all on” command. 2 2 single press sends broadcast “switch all off” command. 8 led management this parameter configures the behavior of the led in "gateway" mode. 0 1 0 0 0 from to description 0 0 led does not acknowledge button action and does not acknowledge result of radio command sent. 1 1 when the end user performs a single press, double press or hold press on a button, led blinks blue to acknowledge the button action. 2 2 when the end user sends a controlled command:  “basic set” command  “central scene notification” command  “multilevel switch stop level change” command led blinks green to acknowledge transmission success or blinks red to acknowledge transmission failed. 3 3 combined behaviors of 0x01 and 0x02 modes. texts
