- Name
- Range Extender
- Brand
- Ring
- Features
- Feature Values Color
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1B00
- Categories
- Network Devices
- Product id
- 0x0301
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Repeater
- Oem version
- HW: 1 FW: 1.10
- Library type
- SLAVE_ENHANCED_232
- Product line
- Ring Alarm
- Supports nwi
- Yes
- Installer icon
- 0x1B00
- Z wave version
- 7.12.1
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x0346
- Product type id
- 0x0401
- Long description
- Ring Alarm Range Extender is a wireless repeater for the Ring Alarm system which helps to improve the range and reliability of the Ring Alarm network by listening for and repeating network communication between the Ring Alarm Base Station and other Ring Alarm end devices. After installing the Range Extender and setting up the Range Extender in the Ring app, the devices added to Ring Alarm’s network can utilize the Range Extender’s routing and repeating to communicate effectively with the Base Station. The Ring Alarm Base Station is required to enable Range Extender features and functions within the Ring app.
- Hardware platform
- EFR32Z
- Short description
- Ring Alarm Range Extender is a wireless repeater for the Ring Alarm system which helps to improve the range and reliability of the Ring Alarm network by listening for and repeating network communication between the Ring Alarm Base Station and other Ring Alarm end devices.
- Product identifier
- Range Extender v2
- Countries / regions
- United States of America
- Supports smart start
- Yes
- Certification number
- ZC12-20050059
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Flag Advanced Size Min Value Max Value Default Value Parameter Values 3
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_CONFIGURATION_V4
- Supported notification types
- Notification Type Event / State Power Management
- Value white association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile Description 1
- From to description 1 60 this parameter is the number base seconds used in the calculation for sleeping between retry messages. 4 led indicator allows led indications on the device to be turned on or off 2 yes 1 0 2 1 from to description 0 2 this parameter is the led indications on the device to be turned on or off 1 hearbeats this parameter is the number minutes between heartbeats. heartbeats are automatic battery reports on a timer after the last event. 2 yes 1 1 70 70 from to description 1 70 this parameter is the number of minutes between heartbeats. 5 supervisory report timeout the number of milliseconds waiting for a supervisory report response to a supervisory get encapsulated command from the sensor before attempting a retry. 2 yes 2 500 5000 1500 from to description 500 5000 the number of milliseconds waiting for number of milliseconds waiting for a supervisory report response to a supervisory get . 2 application retries: number of application level retries attempted for messages either not acked or messages encapsulated via supervision get that did not receive a report. 2 yes 1 0 5 1 from to description 0 5 this parameter is the number of application level retries. texts
- ID Description Value 8
