- Name
- S100 Master Rocker for Roller Blind (Mexico)
- Brand
- Simon
- Features
- Feature Values Firmware Updatable
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1D02
- Categories
- Motor Control
- Product id
- 0x0000
- Device type
- Wall Controller
- Oem version
- HW: 1 FW: 4.24:76.51
- Library type
- SLAVE_ENHANCED
- Product line
- Simon 100
- Supports nwi
- Yes
- Installer icon
- 0x1D02
- Z wave version
- 6.51.07
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x0267
- Product type id
- 0x0005
- Long description
- Master Roller Blind IO is ready to operate with Z-Wave controllers and configured to be managed by Simon100 IO APP using the HUB plug IO for getting a better user experience. Sending the Blind controller by other window covering devices Up/Down/Stop.
- Hardware platform
- ZM5202
- Short description
- Simon Master Roller Blind iO is a wall controller designed to increase the number of control points that manages roller blinds. It is designed as additional control that works over window covering devices.
- Product identifier
- 10005081-13x
- Countries / regions
- United States of America
- Certification number
- ZC10-20016839
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4
- Controlled command classes
- Identifier Name Key Version COMMAND_CLASS_BASIC
- Value updatable by professional/technician neutral wire required z wave scene type value central scene association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Description 1
- From to description 0 0 turns the led off 255 255 turns the led on 25 off value sets the value when the action is off in percentage (0 99) 0 1 0 0 0 from to description 1 99 set the value of off texts
- ID Description Value 2
