- Name
- Smart Water Valve
- Brand
- Alarm.com
- Features
- Feature Values Firmware Updatable
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1500
- Categories
- Water Valves & Irrigation
- Product id
- 0x0002
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Valve
- Oem version
- HW: 1 FW: 1.14:01.00
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Installer icon
- 0x1500
- Z wave version
- 6.81.03
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x0190
- Product type id
- 0x0007
- Long description
- Z-Wave controlled water valve for home water supply.
- Hardware platform
- ZM5202
- Short description
- Z-Wave controlled water valve.
- Product identifier
- ADC-SWV100
- Countries / regions
- United States of America
- Supports smart start
- Yes
- Certification number
- ZC10-19096761
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 69
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_POWERLEVEL
- From to description 2870 2870 magic number reset value texts
- ID Description Value 1
- Value updatable by manufacturer color value white association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
