- Name
- Rehau RE.GUARD Leakage detector
- Brand
- REHAU
- Documents
- Category File Description Image_Product_Supplemental_3
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1500
- Categories
- Water Valves & Irrigation, Security Systems
- Product id
- 0x0001
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Valve
- Oem version
- HW: 1 FW: 1.05:01.06
- Library type
- SLAVE_ENHANCED_232
- Product line
- RE.GUARD
- Supports nwi
- Yes
- Installer icon
- 0x1500
- Z wave version
- 6.71.03
- Frequency plans
- EU: 869.85MHz, 868.40MHz
- Manufacturer id
- 0x0413
- Product type id
- 0x0001
- Long description
- The Rehau RE.GUARD is a water manager which protects your home against water leakages and meassures your consumption of water. It has a highly sophisticated water meter and pressure meter built inside. Its algorithms are able to detect very small microleakages as well as larger leakages like e.g. pipe bursts. The sensibility can be adapted to your needs. Furthermore statistics of your water consumption can be created to help you save water. This product is available at your professional plumber. Made and engineered in Europe
- Hardware platform
- ZM5101
- Short description
- The Rehau RE.GUARD is a water manager which protecs your home against water leakages and meassures your consumption of water
- Association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Description 2
- Product identifier
- 14573121001
- Countries / regions
- European Union
- Certification number
- ZC10-19096760
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 6
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4
- Supported multilevel sensors
- Multilevel Sensor Type Water temperature
- Supported notification types
- Notification Type Event / State Water Alarm
- Supported / controlled meter types
- Meter Type Rate Type Description Water meter
- From to description 1 127 1111111 in binary, 4 fixed schedule time hours 1 1 0 23 0 from to description 0 23 hour of day 5 fixed schedule time minutes minutes in time stamp 1 1 0 59 0 from to description 0 59 minute 7 automatic schedule time interval 1 2 0 168 0 from to description 0 168 how many days 10 micro leakage pressure drop abort 1 2 0 32000 100 from to description 0 32000 pressure drop in k pa 9 micro leakage pressure drop 1 2 0 32000 0 from to description 0 32000 presssure drop in k pa 8 micro leakage mesuring time 1 2 0 32000 100 from to description 0 32000 seconds measuring time 11 number of measurements for micro leackage 1 1 1 99 3 from to description 1 99 how many in one time period 24 max continious liter if operation mode is 1 1 2 0 32000 100 from to description 0 32000 max. liter of water in absent mode 31 backup battery nominal voltage 1 2 0 32000 0 from to description 0 7 shows backup battery voltage 1 operation mode 1 1 0 3 2 from to description 0 0 0 valve (always) off 1 1 1 user absent=not at home=holiday 2 2 2 = user present=at home 3 3 3 = valve (always) on 50 water temperature high threshold 1 2 0 32000 250 from to description 0 32000 1°c = 10; recommended 25°c by international standards texts
- ID Description Value 1
