Heat Pump Thermostat

Name

Brand

MCO Home

Texts

ID Description Value 1

Features

Feature Values Firmware Updatable

Documents

Category Description File Manual_Primary_Lang

Role type

ROLE_TYPE_SLAVE_ALWAYS_ON

User icon

0x1200

Categories

Thermostats, HVAC

Product id

0x5101

S2 classes

S2_UNAUTHENTICATED

Device type

Thermostat - HVAC

Oem version

HW: 255 FW: 3.04

Library type

SLAVE_ENHANCED_232

Supports nwi

Yes

Installer icon

0x1200

Z wave version

6.71.03

Frequency plans

US: 916.00MHz, 908.40MHz

Manufacturer id

0x015F

Product type id

0x0604

Long description

MH6-HP programmable thermostat is a Z-Wave Plus enabled device for indoor temperature control. It is mainly applied to heat pump system for heating/cooling, with 3 modes easily switchable: Schedule, Hold and Holiday. The device is of high reliability and practicability, and it can support up to 3H/2C system. This product can be included and operated in any Z-Wave network with other Z-Wave certified devices from any other manufacturers.

Hardware platform

ZM5202

Short description

MH6-HP programmable thermostat is a Z-Wave Plus enabled device for indoor temperature control.

Product identifier

MH6-HP

Countries / regions

United States of America

Certification number

ZC10-18086210

Radio range z wave (m)

40

Supports explorer frames

Yes

Supported command classes

Identifier Name Key Version COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4

Controlled command classes

Identifier Name Key Version COMMAND_CLASS_THERMOSTAT_MODE_V3

Supported multilevel sensors

Multilevel Sensor Type Air temperature

Value updatable by professional/technician switch load capacity current value output <1 a neutral wire required outdoor use sensors value air temperature thermostat hvac systems supported value heat pump thermostat modes value heat cool auto thermostat power source value power stealing (hard wired 24 v) association groups

Group Number Maximum Nodes Supported End Point ID Description 1
