- Name
- Scene Controller
- Brand
- Ness
- Features
- Feature Values Battery Type
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_PORTABLE
- User icon
- 0x1600
- Categories
- All Controllers, Handheld Controller
- Product id
- 0x000B
- Device type
- Wall Controller
- Oem version
- HW: 1 FW: 1.00
- Library type
- SLAVE_ENHANCED_232
- Product line
- 5P
- Supports nwi
- Yes
- Installer icon
- 0x1600
- Z wave version
- 6.51.08
- Frequency plans
- ANZ: 919.80MHz, 921.40MHz
- Manufacturer id
- 0x0208
- Product type id
- 0x0202
- Long description
- The Scene Controller is a wireless, portable and rechargeable scene switch. It can control a Z-Wave device, such as smart plug, smart dimmer with a Z-Wave gateway. You can also activate a scene like sleep scene, movie scene and entertainment scene with it.
- Hardware platform
- ZM5101
- Short description
- The Scene Controller is a wireless, portable and rechargeable scene switch. It can control a Z-Wave device, such as smart plug, smart dimmer with a Z-Wave gateway.
- Product identifier
- ZA-207001
- Countries / regions
- Australia
- Certification number
- ZC10-20106991
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 254
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_POWERLEVEL
- Controlled command classes
- Identifier Name Key Version COMMAND_CLASS_BATTERY
- Supported multilevel sensors
- Multilevel Sensor Type General purpose
- Supported notification types
- Notification Type Event / State Smoke Alarm
- Value lir2450 battery quantity value 1 z wave scene type value central scene association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Description 2
- From to description 0 0 unlock all configuration parameters. 1 1 lock all configuration parameters 255 reset scene controller reset scene controller and remove from the z wave network 0 4 1 1431655765 1 from to description 1431655765 1431655765 reset scene controller and remove from the z wave network texts
- ID Description Value 23
