- Name
- Zipabox 2
- Brand
- Zipato
- Texts
- ID Description Value 24
- Features
- Feature Values Z-Wave Scene Type
- Documents
- Category Description File Adv_Manual
- Role type
- ROLE_TYPE_CONTROLLER_CENTRAL_STATIC
- User icon
- 0x0500
- Categories
- All Controllers, Gateway Controller
- Product id
- 0x0002
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED, S2_ACCESS_CONTROL
- Device type
- Gateway
- Oem version
- HW: 1 FW: 7.15:07.13:02.03
- Library type
- CONTROLLER_BRIDGE
- Product line
- Zipato
- Supports nwi
- Yes
- Installer icon
- 0x0500
- Z wave version
- 7.15.2
- Frequency plans
- EU: 869.85MHz, 868.40MHz
- Manufacturer id
- 0x0131
- Product type id
- 0x0001
- Long description
- Enjoy the benefits of a connected smart home with the Zipabox2. This next-generation controller connects seamlessly to a vast array of smart devices so you can profit from energy savings, protect your home, and control who has access. Its modular nature enables you to extend its functionality with support for most existing home automation protocols such as Z-Wave™.
- Hardware platform
- EFR32Z
- Short description
- Home automation controller that allows you to connect various sensors and other automation devices for a variety of purposes, such as security, surveillance, elderly care, comfort, and energy efficiency.
- Product identifier
- zb2.zweu
- Countries / regions
- European Union
- Supports smart start
- Yes
- Certification number
- ZC12-22010333
- Radio range z wave (m)
- 40
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_NETWORK_MANAGEMENT_INSTALLATION_MAINTENANCE_V2
- Controlled command classes
- Identifier Name Key Version COMMAND_CLASS_NETWORK_MANAGEMENT_INSTALLATION_MAINTENANCE_V2
- Supported / controlled meter types
- Meter Type Rate Type Description Electric meter
- Value central scene color value white communications connections value ethernet (wired) ethernet (wireless/wi fi) communications protocol value manufacturer proprietary protocol firmware updatable value updatable by consumer via internet association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Description 1
