Micro Module Switch Double w.meter

Loading…

Micro Module Switch Double w.meter — Zipato — Off Screen Space

More specs

Name: Micro Module Switch Double w.meter
Brand: Zipato
Features: Feature Values Firmware Updatable
Documents: Category Description File Manual_Primary_Lang
Role type: ROLE_TYPE_SLAVE_ALWAYS_ON
User icon: 0x0700
Categories: Energy Meters, All Lighting Devices, On/Off Switches/Devices
Product id: 0x0012
Device type: On/Off Power Switch
Oem version: HW: 1 FW: 1.08
Library type: SLAVE_ENHANCED_232
Supports nwi: Yes
Installer icon: 0x0700
Z wave version: 6.51.02
Frequency plans: EU: 869.85MHz, 868.40MHz
Manufacturer id: 0x0131
Product type id: 0x0001
Long description: This product can be operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers. All non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network. Micromodule Switch Double is a transceiver which is a Z-Wave Plus enabled device and is fully compatible with any Z-Wave enabled network. Mini size design allow the module to be easily hidden into the wall box which is good for the house decoration. There are many kinds of application for using the module to switch AC power ON and OFF, one of which is the light control. The new smart relay calibration technology can reduce the inrush current caused by the load and let the module work perfectly with many kinds of light like incandescent, fluorescent and LED light. This Micromodule is able to detect Instant power wattage and overload wattage (current 7.5A) of connected light or appliances. When detecting overload state, the switch will be disabled and its ON/OFF button will be locked during which LED will flash repeatedly. Unplugging and reconnecting the Module will reset its overload condition to normal status.
Hardware platform: SD3502
Short description: Micromodule Switch Double is a transceiver which is a Z-Wave Plus enabled device and is fully compatible with any Z-Wave enabled etwork.
Product identifier: ph-pan04.eu
Countries / regions: European Union
Certification number: ZC10-17065647
Configuration parameters: Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 3
Supports explorer frames: Yes
Supported command classes: Identifier Name Key Version COMMAND_CLASS_SCENE_ACTUATOR_CONF
Supported / controlled meter types: Meter Type Rate Type Description Electric meter
Value updatable by consumer by rf switch load capacity current value 7.5 a supported meter type value electric energy color value white electric load type value incandescent switch type value push button association groups: Group Number Maximum Nodes Supported End Point ID Description 1

From to description 1 1 1: relay1 2 2 2: relay2 3 3 3: relay1 & relay2 6 threshold of kwh for load caution this is a warning when the kwh of load exceeds preset threshold value, if the setting value is 1000, when the accumulated power consumption of relay1 or relay2 exceeds this value, micromodule will send kwh meter report command to the node of corresponding group, the range of the setting value is from 10 to 1000, and the default value is 750. 0 2 0 0 10000 from to description 1 10000 10000*1 kwh = 10000 kwh 8 auto off timer whenever micromodule switches to on, the auto off timer begin to count down. after the timer decrease to zero, it will switch off automatically. however if auto off timer is set as 0, the auto off function will be disabled. the default setting is 0. 0 2 0 0 0 from to description 0 0 0: disable auto off function 1 32767 1 0x7 fff: 1s 32767s 9 rf switch off command mode whenever a switch off command, basic set , binary switch set, switch all off, is received, it could be interpreted as 4 kinds of commands. 1.switch off : it switches to off state. the default setting is switch off. 2.ignore : the switch off command will be ignored. 3.switch toggle : it switches to the inverse of current state. 4.switch on : it switches to on state. 0 1 0 0 0 from to description 0 0 0: switch off 1 1 1: ignore 2 2 2: switch toogle 3 3 3:switch on 10 existence of endpoint3 multi channel command is a good way to control relay1 and relay2 of switch individually. the endpoint3 of micromodule is related to both relay1 and relay2. in some condition it becomes redundant in multi channel command class. when the existence of endpoint3 is set as 2, the endpoint3 will be disabled. the default value is 1. endpoint1 and endpoint2 are fixed, only endpoint3 is dynamic. 0 1 0 0 1 from to description 1 1 1: endpoint exist 2 2 2: no endpoint3 5 threshold of current for load caution this is a warning when the wattage of load over the preset threshold value, if the setting value is 750, when the load wattage of relay1 or relay2 over this value, micromodule will send watt meter report command to the node of correspond group, the range of the setting value is from 10 to 750, and the default value is 750. 0 2 0 0 750 from to description 10 750 750*0.01 a = 7.5 a 7 restore switch state mode whenever the ac power return from lost, micromodule will restore the switch state which could be switch off, last switch state, switch on. the default setting is last switch state. 0 1 0 0 1 from to description 0 0 0: switch off 1 1 1: last switch state 2 2 2: switch on 1 watt meter report period if the setting is configured for 1hour (set value =720), micromodule will report its instant power consumption every 1 hour to the node of correspond group. the maximum interval to report its instant power consumption is 45 hours (5s*32767/3600=45hr). 0 2 0 0 720 from to description 1 32767 5*720s=3600s=1 hour 2 kwh meter report period if the setting is configured for 1hour (set value =6), micromodule will report its accumulated power consumption (kw/h) every 1 hour to the node of correspond group. the maximum interval to report its accumulated power consumption (kw/h) is 227.55 days (10min*32767/1440=227.55 days). 0 2 0 0 6 from to description 1 32767 6*10min= 1 hour 4 edge or pulse mode or edge toggle mode manual switch s1 and s2 can set to edge mode or pulse mode or edge toggle mode, default value is edge mode. 1.edge mode : this mode is suitable for the bi stable wall switch that has indicator point on the micromodule, and the same position correspond to same state of relay1 and relay2. if the switch’s relay changes the state because of receiving z wave rf command, it may need two switchings (switch on to off or switch off to on) to let relay back to the corresponding state. 2.pulse mode : this mode is suitable for the toggle type wall switch to swap the state of relay1 or relay2. 3. edge toggle mode : this mode is suitable for the normal bi stable switch, every state change of the wall switch will also swap the state of relay1 or relay2. 0 1 0 0 1 from to description 1 1 1: edge mode 2 2 2: pulse mode 3 3 3: edge toggle mode texts
