Energy Consumption Monitor Energiemonitor Z-Wave, 230V Model Number — COQON — Off Screen Space

Off Screen Space

Energy Consumption Monitor Energiemonitor Z-Wave, 230V Model Number

COQON · Energy Meter

Energy Consumption Monitor Energiemonitor Z-Wave, 230V Model Number

View all COQON products

Connectivity: Z-WaveCategory: Energy Meter

Z-WaveCertified

The power monitor measures and registers power consumption to help users understand their energy consumption. The measurement takes place per circuit. This information may be useful for those who want to reduce their energy consumption or use energy-efficient behavior. They provide insights into areas in their home where more energy is consumed than in others. Product Compliance: This product meets the essential requirements of (RED) 2014/53 / EU and 2011/65 / EU. The full text of the EU Declaration of Conformity can be found on www.coqon.de. Technical specifications: Model no. EMHTZ001 Mains voltage 230V, 50 Hz Ambient temperature 0-45 ° C Dimensions 100x100x31mm Radio language Z-Wave Plus

Want to buy adds it to your wish list and follows COQON for updates. I own it adds it to your collection.

Compare

vs Competitor ▾

Connectivity

Z-Wave

Firmware

Current version HW: 0 FW: 1.03

Specifications

Overview

Company: COQON
Category: Energy Meter
Device type: Sub Energy Meter

Connectivity

Standard / protocol: Z-Wave
Connectivity: Z-Wave
Transport: Z-Wave
Spec version: 6.71.01
Z-Wave frequency: EU: 869.85MHz, 868.40MHz

Certification & compliance

Certificate ID

Community tags

Be the first to tag this page — tags appear right away. Try a theme, capability, or subject (e.g. WWII, heist, slow burn, time travel, A24).

More specs

Name: Energy Consumption Monitor Energiemonitor Z-Wave, 230V Model Number
Brand: COQON
Features: Feature Values Color
Documents: Category Description File Manual_Primary_Lang
Role type: ROLE_TYPE_SLAVE_ALWAYS_ON
User icon: 0x1000
Categories: Energy Meters
Product id: 0x1003
S2 classes: S2_UNAUTHENTICATED
Device type: Sub Energy Meter
Oem version: HW: 0 FW: 1.03
Library type: SLAVE_ENHANCED_232
Supports nwi: Yes
Installer icon: 0x1000
Z wave version: 6.71.01
Frequency plans: EU: 869.85MHz, 868.40MHz
Manufacturer id: 0x0140
Product type id: 0x0803
Long description: The power monitor measures and registers power consumption to help users understand their energy consumption. The measurement takes place per circuit. This information may be useful for those who want to reduce their energy consumption or use energy-efficient behavior. They provide insights into areas in their home where more energy is consumed than in others. Product Compliance: This product meets the essential requirements of (RED) 2014/53 / EU and 2011/65 / EU. The full text of the EU Declaration of Conformity can be found on www.coqon.de. Technical specifications: Model no. EMHTZ001 Mains voltage 230V, 50 Hz Ambient temperature 0-45 ° C Dimensions 100x100x31mm Radio language Z-Wave Plus
Hardware platform: ZM5101
Short description: Power monitor to measure and register the power consumption of individual circuits. Measurement per circuit. The power monitor helps you to represent, reduce and optimize the power consumption in subareas of your everyday life.
Product identifier: EMHTZ001
Countries / regions: European Union
Certification number: ZC10-18086207
Radio range z wave (m): 40
Configuration parameters: Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 4
Supports explorer frames: Yes
Supported command classes: Identifier Name Key Version COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4
Supported / controlled meter types: Meter Type Rate Type Description Electric meter
Value white firmware updatable value updatable by consumer by rf supported meter type value electric energy association groups: Group Number Maximum Nodes Supported End Point ID Description 1

From to description 0 30000 valid values 0 30000 5 clamp 1 threshold change in wattage to induce an automatic report (clamp 1) 0 2 0 0 50 from to description 0 30000 valid values 0 30000 6 clamp 2 threshold change in wattage to induce an automatic report (clamp 2) 0 2 0 0 50 from to description 0 30000 valid values 0 30000 7 clamp 3 threshold change in wattage to induce an automatic report (clamp 3) 0 2 0 0 50 from to description 0 30000 valid values 0 30000 8 clamp 4 threshold change in wattage to induce an automatic report (clamp 4) 0 2 0 0 50 from to description 0 30000 valid values 0 30000 9 wattage percentage change percentage change in wattage to induce an automatic report (wohle em) 0 1 0 0 10 from to description 0 100 valid values 0 100 10 clamp 1 percentage change in wattage to induce an automatic report (clamp 1) 0 1 0 0 10 from to description 0 100 valid values 0 100 11 clamp 2 percentage change in wattage to induce an automatic report (clamp 2) 0 1 0 0 10 from to description 0 100 valid values 0 100 101 auto report kwh auto report kwh 0 1 0 0 1 from to description 0 31 valid values 0 31, bit 0: whole em, bit 1: clamp 1, bit 2: clamp 2, bit 3: clamp 3, bit 4: clamp 4 102 auto report w auto report w 0 1 0 0 1 from to description 0 31 valid values 0 31, bit 0: whole em, bit 1: clamp 1, bit 2: clamp 2, bit 3: clamp 3, bit 4: clamp 4 103 auto report v auto report v 0 1 0 0 0 from to description 0 31 valid values 0 31, bit 0: whole em, bit 1: clamp 1, bit 2: clamp 2, bit 3: clamp 3, bit 4: clamp 4 104 auto report a auto report a 0 1 0 0 0 from to description 0 31 valid values 0 31, bit 0: whole em, bit 1: clamp 1, bit 2: clamp 2, bit 3: clamp 3, bit 4: clamp 4 105 auto report k var auto report k var 0 1 0 0 0 from to description 0 31 valid values 0 31, bit 0: whole em, bit 1: clamp 1, bit 2: clamp 2, bit 3: clamp 3, bit 4: clamp 4 111 time interval auto report k wh the time interval of auto report k wh 0 4 0 0 0 from to description 0 1 valid values 0x1 e 0x7 fffffff 112 time interval auto report w the time interval of auto report w 0 4 0 0 0 from to description 0 1 valid values 0x1 e 0x7 fffffff 113 time interval auto report v the time interval of auto report v 0 1 0 0 0 from to description 0 1 valid values 0x1 e 0x7 fffffff 114 time interval auto report a the time interval of auto report a 0 1 0 0 0 from to description 0 1 valid values 0x1 e 0x7 fffffff 115 time interval auto report k var the time interval of auto report k var 0 1 0 0 0 from to description 0 1 valid values 0x1 e 0x7 fffffff 2 energy detection mode energy detection mode 0 1 0 0 0 from to description 2 2 2 = report positive / negative power, only report energy positive part (consuming electricity). 0 0 0 = report power, energy absolute value. 3 3 3 = report positive / negative power, only report energy negative part (generating electricity). 1 1 1 = report positive / negative power, report the algebraic sum energy. 3 selective reporting enable selective reporting only when power change reaches a certain threshold or percentage set in parameters 4 11 below. this is used to reduce the network traffic. 0 1 0 0 1 from to description 0 0 0 = disable 1 1 1 = enable texts
