Smart Meter

Name

Smart Meter

Brand

QUBINO

Features

Feature Values Switch Load Capacity Current

Documents

Category Description File Manual_Primary_Lang

Role type

ROLE_TYPE_SLAVE_ALWAYS_ON

User icon

0x1700

Categories

Energy Meters

Product id

0x0052

S2 classes

S2_UNAUTHENTICATED, S2_AUTHENTICATED

Device type

Whole Home Meter - Simple

Oem version

HW: 65 FW: 7.08:108.00

Library type

SLAVE_ENHANCED_232

Supports nwi

Yes

Installer icon

0x1700

Z wave version

6.71.03

Frequency plans

EU: 869.85MHz, 868.40MHz

Manufacturer id

0x0159

Product type id

0x0007

Long description

The Qubino Smart Meter can be used in residential, industrial and utility applications. It measures energy directly in 2-wire networks by means of fast sampling of voltage and current signals. It calculates energy, power and power factor from the measured signals. You can control the device through the Z-Wave network. The Qubino Smart Meter can operate across a wide temperature range, from a chilly -15˚C to a scorching 55˚C (5˚F–131˚F). Every device also acts as a repeater in order to improve the range and stability of the Z-Wave network.

Hardware platform

ZM5202

Short description

The Qubino Smart Meter is an extremely versatile and powerful Z-Wave device for measuring energy in a single-phase electrical power network of up to 65A. A built-in microprocessor calculates energy, power and power factor from the measured signals. It is designed to be mounted on a DIN rail.

Product identifier

ZMNHTD1

Countries / regions

European Union

Certification number

ZC10-18086203

Radio range z wave (m)

40

Configuration parameters

Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 42

Supports explorer frames

Yes
