- Name
- Range Extender
- Brand
- Dome
- Features
- Feature Values Firmware Updatable
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1B00
- Categories
- Network Devices
- Product id
- 0x0108
- S2 classes
- S2_UNAUTHENTICATED
- Device type
- Repeater
- Oem version
- HW: 1 FW: 1.01
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Installer icon
- 0x1B00
- Z wave version
- 6.71.01
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x021F
- Product type id
- 0x0003
- Long description
- The Dome Range Extender is designed to improve communication between Z-Wave devices. It amplifies Z-Wave signals and increases the reach of your controller, ensuring your devices stay connected. The Extender has an LED light that works as a nightlight and can also act as an indicator in regular mode. The included suction cup lets you mount the Extender onto any smooth surface while using a micro USB power supply. All these features make the Dome Range extender the perfect choice for your home.
- Hardware platform
- ZM5101
- Short description
- The Dome Range Extender is designed to improve communication between Z-Wave devices by amplifying Z-Wave signals.
- Product identifier
- DMEX1
- Countries / regions
- United States of America
- Certification number
- ZC10-18076183
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4
- Value updatable by consumer by rf color value white association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
- From to description 0 10 night light off threshold 2 night light "on" threshold this parameter sets the luminance (brightness) level at which night light is turned on. this is a unitless value that can be set to any value from 0 10, with a default value of 5. the higher this value, the brighter the ambient light must be to turn on the night light. 0 1 0 0 5 from to description 1 10 night light on threshold texts
- ID Description Value 5
