- Name
- TBZ500 Thermostat
- Brand
- Ecolink Intelligent Technology
- Features
- Feature Values Battery Type
- Is flirs
- Yes
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1200
- Categories
- Thermostats, HVAC
- Product id
- 0x5439
- S2 classes
- S2_UNAUTHENTICATED
- Device type
- Thermostat - HVAC
- Oem version
- HW: 4 FW: 6.08:03.00
- Library type
- SLAVE_ROUTING
- Product line
- Thermostat
- Supports nwi
- Yes
- Installer icon
- 0x1200
- Z wave version
- 6.82.00
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x014A
- Product type id
- 0x5442
- Long description
- The TBZ500 is a Z-Wave® wireless digital thermostat that supports both 24VAC and battery operation. Designed to control the majority of HVAC systems including standard gas/electric type and heat pump systems. The TBZ500 contains a robust thermostat interface and is designed for use with communicating systems where remote monitoring and/or remote control are desired.
- Hardware platform
- ZM5202
- Short description
- TBZ500 Z-Wave® thermostat paired with a security system provides greater control of your energy and can remotely control, automate and monitor the home’s temperature.
- Product identifier
- TBZ500
- Countries / regions
- United States of America
- Supports smart start
- Yes
- Certification number
- ZC10-21047015
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_SENSOR_MULTILEVEL_V5
- Supported multilevel sensors
- Multilevel Sensor Type Air temperature
- From to description 0 1 0 = standard 1 = heat pump 2 fan type 4 0 = gas (no fan w/heat) 1 = electric (fan w/heat) 1 1 0 1 0 from to description 0 1 0 = gas (no fan w/heat) 1 = electric (fan w/heat) texts
- ID Description Value 1
- Value aa firmware updatable value updatable by consumer by rf thermostat hvac systems supported value heat only cool only single stage multi stage heat pump thermostat modes value heat cool auto auxiliary/emergency heat fan only auto changeover thermostat power source value battery power stealing (hard wired 24 v) external transformer battery quantity value 4 association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile Description 2
