- Name
- Thermostatic Radiator Valve
- Brand
- Nexa
- Features
- Feature Values Battery Quantity
- Is flirs
- Yes
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_SLEEPING_LISTENING
- User icon
- 0x1200
- Categories
- Sensors, Thermostats
- Product id
- 0x0001
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Thermostat - HVAC
- Oem version
- HW: 1 FW: 1.01:00.00
- Library type
- SLAVE_ENHANCED_232
- Product line
- Z-Wave Plus 500 series
- Supports nwi
- Yes
- Installer icon
- 0x1200
- Z wave version
- 6.81.03
- Frequency plans
- EU: 869.85MHz, 868.40MHz
- Manufacturer id
- 0x0060
- Product type id
- 0x0015
- Long description
- Thermostatic Radiator Valves (TRVs) sense the air temperature around them and regulate the flow of water through the radiator which they are fitted to. They can be set at a level that gives you the room temperature you want. These settings may have to be different in each room, and you can set the TRVs to suit each room and then leave them to do their job. The device can be set temperature by manual or by gateway.
- Hardware platform
- SD3502
- Short description
- Thermostatic Radiator Valves (TRVs) sense the air temperature around them and regulate the flow of water through the radiator which they are fitted to.
- Product identifier
- ZRT-106
- Countries / regions
- European Union
- Supports smart start
- Yes
- Certification number
- ZC10-22067099
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_POWERLEVEL
- Supported multilevel sensors
- Multilevel Sensor Type Air temperature
- Supported notification types
- Notification Type Event / State Power Management
- Value 2 battery type value 1.5 v aa battery firmware updatable value updatable by consumer by rf thermostat hvac systems supported value heat only thermostat modes value heat energy save heat thermostat power source value battery association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Description 1
- From to description 1 255 minutes 2 parameter 2 temperature offset for internal sensor 1 1 80 80 0 from to description 80 80 80~+80 offsets the measured temperature by 8.0℃~+8.0℃ 6 parameter 6 open window detect function 1 1 0 1 0 from to description 0 1 0: disable 1: enable 8 parameter 8 open window detect temperature drop setting 1 1 4 8 4 from to description 4 8 4=2℃ , 5=2.5℃ 6= 3℃, 7=3.5℃, 8=4℃ 10 parameter 10 manual override takeover period 1 1 1 48 8 from to description 1 48 1~48, means 30mins to 24hrs (8=4hrs) texts
- ID Description Value 8
