- Name
- Range Extender
- Brand
- Oomi
- Features
- Feature Values Firmware Updatable
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1B00
- Categories
- Network Devices
- Product id
- 0x0075
- Device type
- Repeater
- Oem version
- HW: 117 FW: 1.03
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Installer icon
- 0x1B00
- Z wave version
- 6.51.09
- Frequency plans
- US: 916.00MHz, 908.40MHz
- Manufacturer id
- 0x016A
- Product type id
- 0x0104
- Long description
- Oomi Range Extender is a Z-Wave mesh network repeater which can extend the range of communication between Z-Wave products and assist other devices to reach each other in your Z-Wave network. The Range Extender can also communicate securely via AES 128 wireless Z-Wave commands and supports Over-The-Air (OTA) firmware upgrades.
- Hardware platform
- ZM5101
- Short description
- Oomi Range Extender is a Z-Wave repeater.
- Product identifier
- FT117-A01
- Countries / regions
- United States of America
- Certification number
- ZC10-17055582
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 82
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_POWERLEVEL
- Value updatable by consumer by rf association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
- From to description 0 0 the green led will remain on for 2 seconds. 1 1 the led remains off state. 252 enable/disable lock configuration enable/disable to lock configuration parameters. 0 1 0 0 0 from to description 0 0 disable 1 1 enable 254 device tag set a device tag for your range extender. 0 2 0 0 0 from to description 1 32767 the available value range is 1 to 32767. 255 reset the bulb reset the bulb to factory default. 0 4 0 0 0 from to description 0 0 reset all configuration parameters to factory default settings 1431655765 1431655765 reset the bulb to factory default. texts
- ID Description Value 1
