- Name
- Thermostat-Heating
- Brand
- Sunricher
- Features
- Feature Values Thermostat Modes
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x1200
- Categories
- Thermostats, HVAC
- Product id
- 0xD013
- S2 classes
- S2_UNAUTHENTICATED
- Device type
- Thermostat - HVAC
- Oem version
- HW: 1 FW: 1.24
- Library type
- SLAVE_ENHANCED_232
- Product line
- SR-ZV9092A
- Supports nwi
- Yes
- Installer icon
- 0x1200
- Z wave version
- 6.82.00
- Frequency plans
- EU: 869.85MHz, 868.40MHz
- Manufacturer id
- 0x0330
- Product type id
- 0x0200
- Long description
- Product features: ● OLED display and touch buttons ● also as remote control other thermostats for heating ● Internal sensor for room temperature , external Internal sensor for floor temperature ● Max Load 3680W @ 230V (resistive load),16A ● Alarm: over current, room temperature over heat ● Electric power measurement ● Internal overheating protection
- Hardware platform
- ZM5101
- Short description
- The Z-Wave™ HVAC controller is a wireless thermostat for heating system, which complies to Z-Wave Plus™ wireless protocol standards. The thermostat has 4 operation modes which can be controlled manually and locally or through remote controlled through Z-Wave primary controller (gateway)
- Product identifier
- SR-ZV9092A-EU
- Countries / regions
- European Union
- Supports smart start
- Yes
- Certification number
- ZC10-21097049
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 10
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4
- Controlled command classes
- Identifier Name Key Version COMMAND_CLASS_THERMOSTAT_MODE_V3
- Supported multilevel sensors
- Multilevel Sensor Type Air temperature
- Supported notification types
- Notification Type Event / State Heat Alarm
- Supported / controlled meter types
- Meter Type Rate Type Description Electric meter
- Value auto changeover firmware updatable value not updatable switch load capacity current switch load capacity volt ampere switch load capacity watts thermostat hvac systems supported value heat only thermostat power source electric load type association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile Description 1
- From to description 1 1 room sensor 2 2 floor sensor 3 3 room+floor sensor 4 parameter 4 whether to recover to settings before power failure or power reset. 1 1 0 1 1 from to description 0 0 use default settings 1 1 recover to settings before power failure or power reset 11 parameter 11 room sensor temperature compensation setting,unit is 0.5℃ 1 1 10 10 0 from to description 10 10 value is 5℃~5℃ 23 parameter 23 is parameter defines which sensor temperature will be displayed on home page 1 1 0 1 0 from to description 0 0 indoor air temperature 1 1 external temperature (floor temperature) 3 parameter 3 vibration level triggered by pressing buttons 1 1 0 2 1 from to description 0 0 disable vibration and buzzer 1 1 low level 2 2 high level 9 parameter 9 select floor temperature sensor type 1 1 1 4 1 from to description 1 1 ntc/10 k b(25/50℃)=3950 2 2 ntc/15 k b(25/50℃)=3950 3 3 ntc/50 k b(25/50℃)=3950 4 4 ntc/100 k b(25/50℃)=3950 8 parameter 8 auto mode (energy save mode) temperature schedule. 1 1 0 1 0 from to description 0 0 use schedule set by user 1 1 use energy save heating temperature set by thermostat setpoint set texts
- ID Description Value 8
