- Name
- Smart Plug
- Brand
- LG Uplus
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- Categories
- Energy Meters, All Lighting Devices, On/Off Switches/Devices
- Product id
- 0x0001
- Device type
- On/Off Power Switch
- Oem version
- HW: 17
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Z wave version
- 6.51.06
- Frequency plans
- KR: 920.90MHz, 921.70MHz, 923.10MHz
- Manufacturer id
- 0x018C
- Product type id
- 0x0042
- Long description
- The apparatus can remotely power to the load connected to the device on / off and can be used to measure the power of the load connected to the device. Also inform you your electricity usage kindly by remote is a smart plugs.
- Hardware platform
- ZM5101
- Short description
- This device measures the amount of electricity and has the ability to power on or off the connected load
- Association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
- Product identifier
- SPD-01
- Countries / regions
- Republic of Korea
- Certification number
- ZC10-15070005
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
- Supports explorer frames
- Yes
- From to description 0 3000 0.00 watt ~ 3000.00 watt 2 periodic measurement value transmission start or stop for the periodically measured value transmission of the power usage default : 1 (0x01) function enable value 0 (0x00) : disable 1 (0x01) : enable 0 1 0 0 1 from to description 0 1 disale/enable 3 start / stop power accumulation usage calculation start / stop power accumulation usage calculation default : 1 (0x01) function enable value 0 (0x00) : disable(stop) 1 (0x01) : enable(start) enable / disable 0 1 0 0 1 from to description 0 1 disable/enable 4 report when the connected device is being used or not. report when the connected device is being used or not. (user can know the device's using status) default : 1 (0x00) function disable value 0 (0x00) : disable(stop) 1 (0x01) : enable(start) ※ if not set up the standby power, it does not function. 0 1 0 0 1 from to description 0 1 disable/enable 5 this sets the periodic measurement value transmission rate. this sets the periodic measurement value transmission rate. the rate set is in increments of 10 minutes. for example, if setting value = 2, transmission time interval = 2 * 10 = 20 minutes. default : 6 ( 60min ) value 1(0x01) : 10 min ~ 144 (0x90) : 1440 min 0 1 0 0 6 from to description 1 144 10min~1440min texts
- ID Description Value 1
