- Name
- Smart Gas Controller
- Brand
- LG Uplus
- Features
- Feature Values Battery Type
- Is flirs
- Yes
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_SLEEPING_LISTENING
- User icon
- 0x1500
- Categories
- Gas Valves
- Product id
- 0x0001
- Device type
- Valve
- Oem version
- HW: 1 FW: 39.132
- Library type
- SLAVE_ENHANCED_232
- Supports nwi
- Yes
- Installer icon
- 0x1500
- Z wave version
- 6.61.00
- Frequency plans
- KR: 920.90MHz, 921.70MHz, 923.10MHz
- Manufacturer id
- 0x018B
- Product type id
- 0x0040
- Long description
- U+ Gas lock helps users easily check and turn off the gas valves in home from anywhere. It detects dangerous temperature and alerts potential danger situations so that users can handle a problem. In addition, users can set time to lock gas valves against danger.
- Hardware platform
- ZM5101
- Short description
- Gas Valve Remote Locker
- Product identifier
- GCR-01
- Countries / regions
- Republic of Korea
- Certification number
- ZC10-17055595
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_POWERLEVEL
- Value aa color value white firmware updatable value not updatable ip (ingress protection) rated outdoor use battery quantity value 4 association groups
- Group Number Maximum Nodes Supported End Point ID Description 1
- From to description 0 3 sound volume setting 2 valve auto lock time setting this must be done when the gas valve is open. upper byte value: hour, lower byte value: minute, setting range : 2min ~9hr 59min (0x0002 ~ 0x093 b) 0 2 0 0 256 from to description 2 2363 00(0hr)02(2min) ~ 09(9hr)3 b(59min) texts
- ID Description Value 5
