- Name
- Radio I/O Modul Floor
- Brand
- myTEM SmartHome
- Features
- Feature Values Electric Load Type
- Documents
- Category Description File Manual_Primary_Lang
- Role type
- ROLE_TYPE_SLAVE_ALWAYS_ON
- User icon
- 0x0800
- Categories
- Sensors, All Lighting Devices, On/Off Switches/Devices, HVAC
- Product id
- 0x000A
- S2 classes
- S2_UNAUTHENTICATED, S2_AUTHENTICATED
- Device type
- Binary Switch
- Oem version
- HW: 0 FW: 1.00:00.07
- Library type
- SLAVE_ENHANCED_232
- Product line
- myTEM SmartHome
- Supports nwi
- Yes
- Installer icon
- 0x0800
- Z wave version
- 7.13.2
- Frequency plans
- EU: 869.85MHz, 868.40MHz
- Manufacturer id
- 0x034E
- Product type id
- 0x0001
- Long description
- The Radio IO Modul Floor MTIOM-101-WL is a universal, Z-Wave compatible module from myTEM for extending your smart home system with additional inputs and outputs. It is a Z-Wave device of the type Binary Switch for the use in Europe / Switzerland. Main use is for: - Switching of lights - Switching of single-phase fan motors - Switching of electric blinds or similar shading devices - Operation by means of buttons, sensors via the central server Functions: - Supply voltage 24 VDC ± 10% - Communication via Z-Wave mesh network - 6 digital inputs 24 VDC (DI1 – DI6) for e.g. external switches - 24 VDC power supply, 100 mA, for the digital inputs DI1 – DI6 (VDIout) - 4 analog inputs (AI1 – AI4), which can be used for 0-10 VDC or NTC-, PTC- or PT1000 sensors. Analog inputs can also be used as digital inputs 24 VDC. - 6 digital outputs with potential-free, noiseless SSR 0.1 A, 250 VAC - Manual positions of the outputs via DIP switch for easy commissioning - The device is installed in a control cabinet, mounted on a 35 mm DIN rail
- Hardware platform
- ZGM130
- Short description
- The Radio IO Modul Floor MTIOM-101-WL is a universal, Z-Wave compatible module from myTEM for extending your smart home system with additional inputs and outputs.
- Product identifier
- MTIOM-101-WL
- Countries / regions
- European Union
- Supports smart start
- Yes
- Certification number
- ZC12-20070084
- Radio range z wave (m)
- 40
- Configuration parameters
- Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 11
- Supports explorer frames
- Yes
- Supported command classes
- Identifier Name Key Version COMMAND_CLASS_CONFIGURATION_V4
- Supported multilevel sensors
- Multilevel Sensor Type Air temperature
- Supported notification types
- Notification Type Event / State Power Management
- Value incandescent inductive (e.g. motor) loads controlled value 6 firmware updatable value updatable by consumer by rf association groups
- Group Number Maximum Nodes Supported End Point ID Group Name Profile Description 1
- From to description 1 1200 value tells at what interval [0.1min] notification for di 5 will we sent 5 di 2 send interval [min] see manual 2 2 1 1200 50 from to description 1 1200 value tells at what interval [0.1min] notification for di 2 will we sent 6 di 3 send enable see manual 2 2 0 1 0 from to description 0 0 notifications for di 3 are disabled 1 1 notifications for di 3 are enabled 4 di 2 send enable see manual 2 2 0 1 0 from to description 0 0 notifications for di 2 are disabled 1 1 notifications for di 2 are enabled 8 di 4 send enable see manual 2 2 0 1 0 from to description 0 0 notifications for di 4 are disabled 1 1 notifications for di 4 are enabled 7 di 3 send interval[min] see manual 2 2 1 1200 50 from to description 1 1200 value tells at what interval [0.1min] notification for di 3 will we sent 9 di 4 send interval [min] see manual 2 2 1 1200 50 from to description 1 1200 value tells at what interval [0.1min] notification for di 4 will we sent 24 ai 3 send enable see manual 2 2 0 1 0 from to description 0 0 sending ai 3 values disabled 1 1 sending ai 3 values enabled 25 ai 3 sensor select see manual 2 2 0 5 0 from to description 4 4 configure ai 3 for 0 10 v sensor 1 1 configure ai 3 for ntc 10k ohm thermistor 3 3 configure ai 3 for pt1000 thermistor 2 2 configure ai 3 for ptc 1k ohm thermistor 5 5 configure ai 3 for digital input 0 0 configure ai 3 for ntc 5k ohm thermistor 31 ai 4 send interval [min] see manual 2 2 1 1200 50 from to description 1 1200 value tells at what interval [0.1min] sensor values for ai 4 will be sent 17 ai 1 send delta temp [k] see manual 1 2 1 100 5 from to description 1 100 value tells at what temperature difference [0.1 k]for ai 1 will be sent 23 ai 2 send delta volt [v] see manual 2 2 1 100 5 from to description 1 100 value tells at what voltage difference [0.1 v]for ai 2 will be sent 2 di 1 send enable see manual 2 2 0 1 0 from to description 0 0 notifications for di 1 are disabled 1 1 notifications for di 1 are enabled 3 di 1 send interval [min] see manual 2 2 1 1200 50 from to description 1 1200 value tells at what interval [0.1min] notification for di 1 will we sent 10 di 5 send enable see manual 2 2 0 1 0 from to description 1 1 notifications for di 5 are enabled 0 0 notifications for di 5 are disabled 1 heartbeat rate [min] see manual 2 2 1 1440 60 from to description 1 1440 value tells at what interval [min] heartbeat will be sent texts
